Archivers — Solana’s Solution to Petabytes of Blockchain Data Storage

Proof of Replication in Further Depth

The basic idea of Proof of Replication is to encrypt a dataset with a public symmetric key using CBC encryption, and then hash the encrypted dataset. This method is explained in detail in Filecoin’s Proof of Replication Technical Report. Unfortunately, the problem with this approach is that it is vulnerable to attack.

For example, a dishonest storage node can stream the encryption and delete as it’s hashed. The simple solution is to force the hash to be done on the reverse of the encryption, or perhaps with a random order. This ensures that all the data is present during the generation of the proof, and it also requires the Validator to have the entirety of the encrypted data present for verification of every proof of every identity. The space required to validate becomes (Number of CBC keys)*(data size).

We improve on this approach by randomly sampling the encrypted blocks at a faster pace than the speed of encryption, and record the hash of those samples into the PoH ledger. Thus the blocks stay in the exact same order for every PoRep and verification can stream the data and verify all the proofs in a single batch. This way, we can verify multiple proofs concurrently, each one on its own CUDA core.

With the current generation of graphics cards, the Solana network can support up to 1500 replication identities or symmetric keys per GPU card. The total space required for verification is (2 CBC blocks) * (Number of CBC keys), with core count of equal to (Number of CBC keys). A CBC block is expected to be 1MB in size.

Next, we have to construct a game between Validators and Archivers that ensures that Archivers are generating proofs, and that validators are actually verifying PoReps.

To begin producing PoReps of the ledger, the Replicator client does the following:

1. Clients sign a PoH hash at a regular period
2. Signature is used as the source of randomness to pick a specific slice of the ledger
3. Signature is used to create a symmetric CBC key and the client encodes the slice of the ledger with the key.

Since each client sligns the same PoH hash, the signatures are randomly distributed between all the clients. Clients then continuously sample the encrypted sample:

1. Clients sign a PoH hash at a regular period
2. Signature is used as the source of randomness to sample 1 byte per 1MB of the slice.
3. Samples are hashed with SHA256

All the clients are forced to use the same PoH hash value as the signature. Since the signature tied to PoH, the resulting hash of samples is unique to that point in time and to that specific replication.

Validators in turn check the clients’ proofs:

1. Validator declares how many PoReps it can verify, based on number of GPU cores
2. Periodically validators will sign a PoH hash
3. The signature is used to select a slice of the ledger to verify, and a mask to select which samples to verify up to the capacity of the validator
4. Validator uploads the proofs that failed verification

A client can challenge a Validator for a failed proof by fishing for lazy validators. To prevent grinding attacks, clients must use the same keypair identity continuously. To prevent spam, all the messages in the protocol incur tx fees. Archivers earn rewards based on the number of successful submitted proofs. Validators earn a stake weighted reward for verifying proofs, and fishermen earn a reward by taking a validators slashed coins when fishermen publish a proof of a fake proof.
