Compressed NFTs

Compressed NFTs

Summary #

  • Compressed NFTs (cNFTs) use State Compression to hash NFT data and store the hash onchain in an account using a concurrent Merkle tree structure
  • The cNFT data hash can’t be used to infer the cNFT data, but it can be used to verify if the cNFT data you’re seeing is correct
  • Supporting RPC providers index cNFT data offchain when the cNFT is minted so that you can use the Read API to access the data
  • The Metaplex Bubblegum program is an abstraction on top of the State Compression program that enables you to more simply create, mint, and manage cNFT collections

Lesson #

Compressed NFTs (cNFTs) are exactly what their name suggests: NFTs whose structure takes up less account storage than traditional NFTs. Compressed NFTs leverage a concept called State Compression to store data in a way that drastically reduces costs.

Solana’s transaction costs are so cheap that most users never think about how expensive minting NFTs can be at scale. The cost to set up and mint 1 million traditional NFTs is approximately 24,000 SOL. By comparison, cNFTs can be structured to where the same setup and mint costs 10 SOL or less. That means anyone using NFTs at scale could cut costs by more than 1000x by using cNFTs over traditional NFTs.

However, cNFTs can be tricky to work with. Eventually, the tooling required to work with them will be sufficiently abstracted from the underlying technology that the developer experience between traditional NFTs and cNFTs will be negligible. But for now, you’ll still need to understand the low level puzzle pieces, so let’s dig in!

A theoretical overview of cNFTs #

Most of the costs associated with traditional NFTs come down to account storage space. Compressed NFTs use a concept called State Compression to store data in the blockchain’s cheaper ledger state, using more expensive account space only to store a “fingerprint”, or hash, of the data. This hash allows you to cryptographically verify that data has not been tampered with.

To both store hashes and enable verification, we use a special binary tree structure known as a concurrent Merkle tree. This tree structure lets us hash data together in a deterministic way to compute a single, final hash that gets stored onchain. This final hash is significantly smaller in size than all the original data combined, hence the “compression.” The steps to this process are:

  1. Take any piece of data
  2. Create a hash of this data
  3. Store this hash as a “leaf” at the bottom of the tree
  4. Each leaf pair is then hashed together, creating a “branch”
  5. Each branch is then hashed together
  6. Continually climb the tree and hash adjacent branches together
  7. Once at the top of the tree, a final ”root hash” is produced
  8. Store the root hash onchain as a verifiable proof of the data within each leaf
  9. Anyone wanting to verify that the data they have matches the “source of truth” can go through the same process and compare the final hash without having to store all the data onchain

One problem not addressed in the above is how to make data available if it can’t be fetched from an account. Since this hashing process occurs onchain, all the data exists in the ledger state and could theoretically be retrieved from the original transaction by replaying the entire chain state from origin. However, it’s much more straightforward (though still complicated) to have an indexer track and index this data as the transactions occur. This ensures there is an offchain “cache” of the data that anyone can access and subsequently verify against the onchain root hash.

This process is very complex. We’ll cover some of the key concepts below but don’t worry if you don’t understand it right away. We’ll talk more theory in the state compression lesson and focus primarily on application to NFTs in this lesson. You’ll be able to work with cNFTs by the end of this lesson even if you don’t fully understand every piece of the state compression puzzle.

Concurrent Merkle trees #

A Merkle tree is a binary tree structure represented by a single hash. Every leaf node in the structure is a hash of its inner data while every branch is a hash of its child leaf hashes. In turn, branches are also hashed together until eventually one final root hash remains.

Any modification to leaf data changes the root hash. This causes an issue when multiple transactions in the same slot are attempting to modify leaf data. Since these transactions must execute in series, all but the first will fail since the root hash and proof passed in will have been invalidated by the first transaction to be executed.

A concurrent Merkle tree is a Merkle tree that stores a secure changelog of the most recent changes along with their root hash and the proof to derive it. When multiple transactions in the same slot try to modify leaf data, the changelog can be used as a source of truth to allow for concurrent changes to be made to the tree.

When working with a concurrent Merkle tree, there are three variables that determine the size of the tree, the cost to create the tree, and the number of concurrent changes that can be made to the tree:

  1. Max depth
  2. Max buffer size
  3. Canopy depth

The max depth is the maximum number of hops to get from any leaf to the root of the tree. Since Merkle trees are binary trees, every leaf is connected only to one other leaf. Max depth can then logically be used to calculate the number of nodes for the tree with 2 ^ maxDepth.

The max buffer size is effectively the maximum number of concurrent changes that you can make to a tree within a single slot with the root hash still being valid.

The canopy depth is the number of proof nodes that are stored onchain for any given proof path. Verifying any leaf requires the complete proof path for the tree. The complete proof path is made up of one proof node for every “layer” of the tree, i.e. a max depth of 14 means there are 14 proof nodes. Every proof node adds 32 bytes to a transaction, so large trees would quickly exceed the maximum transaction size limit without caching proof nodes onchain.

Each of these three values, max depth, max buffer size, and canopy depth, comes with a tradeoff. Increasing the value of any of these values increases the size of the account used to store the tree, thus increasing the cost to create the tree.

Choosing the max depth is fairly straightforward as it directly relates to the number of leafs and therefore the amount of data you can store. If you need 1million cNFTs on a single tree, find the max depth that makes the following expression true: 2^maxDepth {'>'} 1million. The answer is 20.

Choosing a max buffer size is effectively a question of throughput: how many concurrent writes do you need.

SPL State Compression and Noop Programs #

The SPL State Compression Program exists to make the above process repeatable and composable throughout the Solana ecosystem. It provides instructions for initializing Merkle trees, managing tree leafs (i.e. add, update, remove data), and verifying leaf data.

The State Compression Program also leverages a separate “no op” program whose primary purpose is to make leaf data easier to index by logging it to the ledger state.

Use the Ledger State for storage #

The Solana ledger is a list of entries containing signed transactions. In theory, this can be traced back to the genesis block. This effectively means any data that has ever been put into a transaction exists in the ledger.

When you want to store compressed data, you pass it to the State Compression program where it gets hashed and emitted as an “event” to the Noop program. The hash is then stored in the corresponding concurrent Merkle tree. Since the data passed through a transaction and even exists on the Noop program logs, it will forever exist on the ledger state.

Index data for easy lookup #

Under normal conditions, you would typically access onchain data by fetching the appropriate account. When using state compression, however, it’s not so straightforward.

As mentioned above, the data now exists in the ledger state rather than in an account. The easiest place to find the full data is in the logs of the Noop instruction, but while this data will in a sense exist in the ledger state forever, it will likely be inaccessible through validators after a certain period of time.

To save space and be more performant, validators don’t retain every transaction back to the genesis block. The specific amount of time you’ll be able to access the Noop instruction logs related to your data will vary based on the validator, but eventually you’ll lose access to it if you’re relying directly on instruction logs.

Technically, you can replay transaction state back to the genesis block but the average team isn’t going to do that, and it certainly won’t be performant. Instead, you should use an indexer that will observe the events sent to the Noop program and store the relevant data off chain. That way you don’t need to worry about old data becoming inaccessible.

Create a cNFT Collection #

With the theoretical background out of the way, let’s turn our attention to the main point of this lesson: how to create a cNFT collection.

Fortunately, you can use tools created by Solana Foundation, the Solana developer community, and Metaplex to simplify the process. Specifically, we’ll be using the @solana/spl-account-compression SDK, the Metaplex Bubblegum program, and the Bubblegum program’s corresponding TS SDK @metaplex-foundation/mpl-bugglegum.

Prepare metadata #

Prior to starting, you’ll prepare your NFT metadata similarly to how you would if you were using a Candy Machine. At its core, an NFT is simply a token with metadata that follows the NFT standard. In other words, it should be shaped something like this:

{
  "name": "12_217_47",
  "symbol": "RGB",
  "description": "Random RGB Color",
  "seller_fee_basis_points": 0,
  "image": "https://raw.githubusercontent.com/ZYJLiu/rgb-png-generator/master/assets/12_217_47/12_217_47.png",
  "attributes": [
    {
      "trait_type": "R",
      "value": "12"
    },
    {
      "trait_type": "G",
      "value": "217"
    },
    {
      "trait_type": "B",
      "value": "47"
    }
  ]
}

Depending on your use case, you may be able to generate this dynamically or you might want to have a JSON file prepared for each cNFT beforehand. You’ll also need any other assets referenced by the JSON, such as the image url shown in the example above.

Create Collection NFT #

If you want your cNFTs to be part of a collection, you’ll need to create a Collection NFT before you start minting cNFTs. This is a traditional NFT that acts as the reference binding your cNFTs together into a single collection. You can create this NFT using the @metaplex-foundation/js library. Just make sure you set isCollection to true.

const collectionNft = await metaplex.nfts().create({
  uri: someUri,
  name: "Collection NFT",
  sellerFeeBasisPoints: 0,
  updateAuthority: somePublicKey,
  mintAuthority: somePublicKey,
  tokenStandard: 0,
  symbol: "Collection",
  isMutable: true,
  isCollection: true,
});

Create Merkle tree Account #

Now we start to deviate from the process you would use when creating traditional NFTs. The onchain storage mechanism you use for state compression is an account representing a concurrent Merkle tree. This Merkle tree account belongs to the SPL State Compression program. Before you can do anything related to cNFTs, you need to create an empty Merkle tree account with the appropriate size.

The variables impacting the size of the account are:

  1. Max depth
  2. Max buffer size
  3. Canopy depth

The first two variables must be chosen from an existing set of valid pairs. The table below shows the valid pairs along with the number of cNFTs that can be created with those values.

Max DepthMax Buffer SizeMax Number of cNFTs
388
5832
146416,384
1425616,384
141,02416,384
142,04816,384
156432,768
166465,536
1764131,072
1864262,144
1964524,288
20641,048,576
202561,048,576
201,0241,048,576
202,0481,048,576
246416,777,216
2425616,777,216
2451216,777,216
241,02416,777,216
242,04816,777,216
2651267,108,864
261,02467,108,864
262,04867,108,864
305121,073,741,824
301,0241,073,741,824
302,0481,073,741,824

Note that the number of cNFTs that can be stored on the tree depends entirely on the max depth, while the buffer size will determine the number of concurrent changes (mints, transfers, etc.) within the same slot that can occur to the tree. In other words, choose the max depth that corresponds to the number of NFTs you need the tree to hold, then choose one of the options for max buffer size based on the traffic you expect you’ll need to support.

Next, choose the canopy depth. Increasing the canopy depth increases the composability of your cNFTs. Any time your or another developer’s code attempts to verify a cNFT down the road, the code will have to pass in as many proof nodes as there are “layers” in your tree. So for a max depth of 20, you’ll need to pass in 20 proof nodes. Not only is this tedious, but since each proof node is 32 bytes it’s possible to max out transaction sizes very quickly.

For example, if your tree has a very low canopy depth, an NFT marketplace may only be able to support simple NFTs transfers rather than support an onchain bidding system for your cNFTs. The canopy effectively caches proof nodes onchain so you don’t have to pass all of them into the transaction, allowing for more complex transactions.

Increasing any of these three values increases the size of the account, thereby increasing the cost associated with creating it. Weigh the benefits accordingly when choosing the values.

Once you know these values, you can use the createAllocTreeIx helper function from the @solana/spl-account-compression TS SDK to create the instruction for creating the empty account.

import { createAllocTreeIx } from "@solana/spl-account-compression"

const treeKeypair = Keypair.generate()

const allocTreeIx = await createAllocTreeIx(
  connection,
  treeKeypair.publicKey,
  payer.publicKey,
  { maxDepth: 20; maxBufferSize: 256 },
  canopyDepth
)

Note that this is simply a helper function for calculating the size required by the account and creating the instruction to send to the System Program for allocating the account. This function doesn’t interact with any compression-specific programs yet.

Use Bubblegum to Initialize Your Tree #

With the empty tree account created, you then use the Bubblegum program to initialize the tree. In addition to the Merkle tree account, Bubblegum creates a tree config account to add cNFT-specific tracking and functionality.

Version 0.7 of the @metaplex-foundation/mpl-bubblegum TS SDK provides the helper function createCreateTreeInstruction for calling the create_tree instruction on the Bubblegum program. As part of the call, you’ll need to derive the treeAuthority PDA expected by the program. This PDA uses the tree’s address as a seed.

import {
	createAllocTreeIx,
	SPL_ACCOUNT_COMPRESSION_PROGRAM_ID,
  SPL_NOOP_PROGRAM_ID,
} from "@solana/spl-account-compression"
import {
  PROGRAM_ID as BUBBLEGUM_PROGRAM_ID,
  createCreateTreeInstruction,
} from "@metaplex-foundation/mpl-bubblegum"

...

const [treeAuthority, _bump] = PublicKey.findProgramAddressSync(
  [treeKeypair.publicKey.toBuffer()],
  BUBBLEGUM_PROGRAM_ID
)

const createTreeIx = createCreateTreeInstruction(
  {
    treeAuthority,
    merkleTree: treeKeypair.publicKey,
    payer: payer.publicKey,
    treeCreator: payer.publicKey,
    logWrapper: SPL_NOOP_PROGRAM_ID,
    compressionProgram: SPL_ACCOUNT_COMPRESSION_PROGRAM_ID,
  },
  {
    maxBufferSize: 256,
    maxDepth: 20,
    public: false,
  },
  BUBBLEGUM_PROGRAM_ID
)

The list below shows the required input for this helper function:

  • accounts - An object representing the accounts required by the instruction. This includes:
    • treeAuthority - Bubblegum expects this to be a PDA derived using the Merkle tree address as a seed
    • merkleTree - The Merkle tree account
    • payer - The address paying for transaction fees, rent, etc.
    • treeCreator - The address to list as the tree creator
    • logWrapper - The program to use to expose the data to indexers through logs; this should be the address of the SPL Noop program unless you have some other custom implementation
    • compressionProgram - The compression program to use for initializing the Merkle tree; this should be the address of the SPL State Compression program unless you have some other custom implementation
  • args - An object representing additional arguments required by the instruction. This includes:
    • maxBufferSize - The max buffer size of the Merkle tree
    • maxDepth - The max depth of the Merkle tree
    • public - When set to true, anyone will be able to mint cNFTs from the tree; when set to false, only the tree creator or tree delegate will be able to min cNFTs from the tree

When submitted, this will invoke the create_tree instruction on the Bubblegum program. This instruction does three things:

  1. Creates the tree config PDA account
  2. Initializes the tree config account with appropriate initial values
  3. Issues a CPI to the State Compression program to initialize the empty Merkle tree account

Feel free to take a look at the program code here.

Mint cNFTs #

With the Merkle tree account and its corresponding Bubblegum tree config account initialized, it’s possible to mint cNFTs to the tree. The Bubblegum instruction to use will be either mint_v1 or mint_to_collection_v1, depending on whether or not you want to the minted cNFT to be part of a collection.

Version 0.7 of the @metaplex-foundation/mpl-bubblegum TS SDK provides helper functions createMintV1Instruction and createMintToCollectionV1Instruction to make it easier for you to create the instructions.

Both functions will require you to pass in the NFT metadata and a list of accounts required to mint the cNFT. Below is an example of minting to a collection:

const mintWithCollectionIx = createMintToCollectionV1Instruction(
  {
    payer: payer.publicKey,
    merkleTree: treeAddress,
    treeAuthority,
    treeDelegate: payer.publicKey,
    leafOwner: destination,
    leafDelegate: destination,
    collectionAuthority: payer.publicKey,
    collectionAuthorityRecordPda: BUBBLEGUM_PROGRAM_ID,
    collectionMint: collectionDetails.mint,
    collectionMetadata: collectionDetails.metadata,
    editionAccount: collectionDetails.masterEditionAccount,
    compressionProgram: SPL_ACCOUNT_COMPRESSION_PROGRAM_ID,
    logWrapper: SPL_NOOP_PROGRAM_ID,
    bubblegumSigner,
    tokenMetadataProgram: TOKEN_METADATA_PROGRAM_ID,
  },
  {
    metadataArgs: Object.assign(nftMetadata, {
      collection: { key: collectionDetails.mint, verified: false },
    }),
  },
);

Notice that there are two arguments for the helper function: accounts and args. The args parameter is simply the NFT metadata, while accounts is an object listing the accounts required by the instruction. There are admittedly a lot of them:

  • payer - the account that will pay for the transaction fees, rent, etc.
  • merkleTree - the Merkle tree account
  • treeAuthority - the tree authority; should be the same PDA you derived previously
  • treeDelegate - the tree delegate; this is usually the same as the tree creator
  • leafOwner - the desired owner of the compressed NFT being minted
  • leafDelegate - the desired delegate of the compressed NFT being minted; this is usually the same as the leaf owner
  • collectionAuthority - the authority of the collection NFT
  • collectionAuthorityRecordPda - optional collection authority record PDA; there typically is none, in which case you should put the Bubblegum program address
  • collectionMint - the mint account for the collection NFT
  • collectionMetadata - the metadata account for the collection NFT
  • editionAccount - the master edition account of the collection NFT
  • compressionProgram - the compression program to use; this should be the address of the SPL State Compression program unless you have some other custom implementation
  • logWrapper - the program to use to expose the data to indexers through logs; this should be the address of the SPL Noop program unless you have some other custom implementation
  • bubblegumSigner - a PDA used by the Bubblegrum program to handle collection verification
  • tokenMetadataProgram - the token metadata program that was used for the collection NFT; this is usually always the Metaplex Token Metadata program

Minting without a collection requires fewer accounts, none of which are exclusive to minting without a collection. You can take a look at the example below.

const mintWithoutCollectionIx = createMintV1Instruction(
  {
    payer: payer.publicKey,
    merkleTree: treeAddress,
    treeAuthority,
    treeDelegate: payer.publicKey,
    leafOwner: destination,
    leafDelegate: destination,
    compressionProgram: SPL_ACCOUNT_COMPRESSION_PROGRAM_ID,
    logWrapper: SPL_NOOP_PROGRAM_ID,
  },
  {
    message: nftMetadata,
  },
);

Interact with cNFTs #

It’s important to note that cNFTs are not SPL tokens. That means your code needs to follow different conventions to handle cNFT functionality like fetching, querying, transferring, etc.

Fetch cNFT data #

The simplest way to fetch data from an existing cNFT is to use the Digital Asset Standard Read API (Read API). Note that this is separate from the standard JSON RPC. To use the Read API, you’ll need to use a supporting RPC Provider. Metaplex maintains a (likely non-exhaustive) list of RPC providers that support the Read API. In this lesson we’ll be using Helius as they have free support for Devnet.

To use the Read API to fetch a specific cNFT, you need to have the cNFT’s asset ID. However, after minting cNFTs, you’ll have at most two pieces of information:

  1. The transaction signature
  2. The leaf index (possibly)

The only real guarantee is that you’ll have the transaction signature. It is possible to locate the leaf index from there, but it involves some fairly complex parsing. The short story is you must retrieve the relevant instruction logs from the Noop program and parse them to find the leaf index. We’ll cover this more in depth in a future lesson. For now, we’ll assume you know the leaf index.

This is a reasonable assumption for most mints given that the minting will be controlled by your code and can be set up sequentially so that your code can track which index is going to be used for each mint. I.e. the first mint will use index 0, the second index 1, etc.

Once you have the leaf index, you can derive the cNFT’s corresponding asset ID. When using Bubblegum, the asset ID is a PDA derived using the Bubblegum program ID and the following seeds:

  1. The static string asset represented in utf8 encoding
  2. The Merkle tree address
  3. The leaf index

The indexer essentially observes transaction logs from the Noop program as they happen and stores the cNFT metadata that was hashed and stored in the Merkle tree. This enables them to surface that data when requested. This asset id is what the indexer uses to identify the particular asset.

For simplicity, you can just use the getLeafAssetId helper function from the Bubblegum SDK. With the asset ID, fetching the cNFT is fairly straightforward. Simply use the getAsset method provided by the supporting RPC provider:

const assetId = await getLeafAssetId(treeAddress, new BN(leafIndex));
const response = await fetch(process.env.RPC_URL, {
  method: "POST",
  headers: { "Content-Type": "application/json" },
  body: JSON.stringify({
    jsonrpc: "2.0",
    id: "my-id",
    method: "getAsset",
    params: {
      id: assetId,
    },
  }),
});

const { result } = await response.json();
console.log(JSON.stringify(result, null, 2));

This will return a JSON object that is comprehensive of what a traditional NFT’s on- and offchain metadata would look like combined. For example, you can find the cNFT attributes at content.metadata.attributes or the image at content.files.uri.

Query cNFTs #

The Read API also includes ways to get multiple assets, query by owner, creator, and more. For example, Helius supports the following methods:

  • getAsset
  • getSignaturesForAsset
  • searchAssets
  • getAssetProof
  • getAssetsByOwner
  • getAssetsByAuthority
  • getAssetsByCreator
  • getAssetsByGroup

We won’t go over most of these directly, but be sure to look through the Helius docs to learn how to use them correctly.

Transfer cNFTs #

Just as with a standard SPL token transfer, security is paramount. An SPL token transfer, however, makes verifying transfer authority very easy. It’s built into the SPL Token program and standard signing. A compressed token’s ownership is more difficult to verify. The actual verification will happen program-side, but your client-side code needs to provide additional information to make it possible.

While there is a Bubblegum createTransferInstruction helper function, there is more assembly required than usual. Specifically, the Bubblegum program needs to verify that the entirety of the cNFT’s data is what the client asserts before a transfer can occur. The entirety of the cNFT data has been hashed and stored as a single leaf on the Merkle tree, and the Merkle tree is simply a hash of all the tree’s leafs and branches. Because of this, you can’t simply tell the program what account to look at and have it compare that account’s authority or owner field to the transaction signer.

Instead, you need to provide the entirety of the cNFT data and any of the Merkle tree’s proof information that isn’t stored in the canopy. That way, the program can independently prove that the provided cNFT data, and therefore the cNFT owner, is accurate. Only then can the program safely determine if the transaction signer should, in fact, be allowed to transfer the cNFT.

In broad terms, this involves a five step process:

  1. Fetch the cNFT's asset data from the indexer
  2. Fetch the cNFT's proof from the indexer
  3. Fetch the Merkle tree account from the Solana blockchain
  4. Prepare the asset proof as a list of AccountMeta objects
  5. Build and send the Bubblegum transfer instruction

The first two steps are very similar. Using your supporting RPC provider, use the getAsset and getAssetProof methods to fetch the asset data and proof, respectively.

const assetDataResponse = await fetch(process.env.RPC_URL, {
  method: "POST",
  headers: { "Content-Type": "application/json" },
  body: JSON.stringify({
    jsonrpc: "2.0",
    id: "my-id",
    method: "getAsset",
    params: {
      id: assetId,
    },
  }),
});
const assetData = (await assetDataResponse.json()).result;

const assetProofResponse = await fetch(process.env.RPC_URL, {
  method: "POST",
  headers: { "Content-Type": "application/json" },
  body: JSON.stringify({
    jsonrpc: "2.0",
    id: "my-id",
    method: "getAssetProof",
    params: {
      id: assetId,
    },
  }),
});
const assetProof = (await assetProofResponse.json()).result;

The third step is to fetch the Merkle tree account. The simplest way to do this is using the ConcurrentMerkleTreeAccount type from @solana/spl-account-compression:

const treePublicKey = new PublicKey(assetData.compression.tree);

const treeAccount = await ConcurrentMerkleTreeAccount.fromAccountAddress(
  connection,
  treePublicKey,
);

Step four is the most conceptually challenging step. Using the three pieces of information gathered, you’ll need to assemble the proof path for the cNFT’s corresponding leaf. The proof path is represented as accounts passed to the program instruction. The program uses each of the account addresses as proof nodes to prove the leaf data is what you say it is.

The full proof is provided by the indexer as shown above in assetProof. However, you can exclude the same number of tail-end accounts from the proof as the depth of the canopy.

const canopyDepth = treeAccount.getCanopyDepth() || 0;

const proofPath: AccountMeta[] = assetProof.proof
  .map((node: string) => ({
    pubkey: new PublicKey(node),
    isSigner: false,
    isWritable: false,
  }))
  .slice(0, assetProof.proof.length - canopyDepth);

Finally, you can assemble the transfer instruction. The instruction helper function, createTransferInstruction, requires the following arguments:

  • accounts - a list of instruction accounts, as expected; they are as follows:
    • merkleTree - the Merkle tree account
    • treeAuthority - the Merkle tree authority
    • leafOwner - the owner of the leaf (cNFT) in question
    • leafDelegate - the delegate of the leaf (cNFT) in question; if no delegate has been added then this should be the same as leafOwner
    • newLeafOwner - the address of the new owner post-transfer
    • logWrapper - the program to use to expose the data to indexers through logs; this should be the address of the SPL Noop program unless you have some other custom implementation
    • compressionProgram - the compression program to use; this should be the address of the SPL State Compression program unless you have some other custom implementation
    • anchorRemainingAccounts - this is where you add the proof path
  • args - additional arguments required by the instruction; they are:
    • root - the root Merkle tree node from the asset proof; this is provided by the indexer as a string and must be converted to bytes first
    • dataHash - the hash of the asset data retrieved from the indexer; this is provided by the indexer as a string and must be converted to bytes first
    • creatorHash - the hash of the cNFT creator as retrieved from the indexer; this is provided by the indexer as a string and must be converted to bytes first
    • nonce - used to ensure that no two leafs have the same hash; this value should be the same as index
    • index - the index where the cNFT’s leaf is located on the Merkle tree

An example of this is shown below. Note that the first 3 lines of code grab additional information nested in the objects shown previously so they are ready to go when assembling the instruction itself.

const treeAuthority = treeAccount.getAuthority();
const leafOwner = new PublicKey(assetData.ownership.owner);
const leafDelegate = assetData.ownership.delegate
  ? new PublicKey(assetData.ownership.delegate)
  : leafOwner;

const transferIx = createTransferInstruction(
  {
    merkleTree: treePublicKey,
    treeAuthority,
    leafOwner,
    leafDelegate,
    newLeafOwner: receiver,
    logWrapper: SPL_NOOP_PROGRAM_ID,
    compressionProgram: SPL_ACCOUNT_COMPRESSION_PROGRAM_ID,
    anchorRemainingAccounts: proofPath,
  },
  {
    root: [...new PublicKey(assetProof.root.trim()).toBytes()],
    dataHash: [
      ...new PublicKey(assetData.compression.data_hash.trim()).toBytes(),
    ],
    creatorHash: [
      ...new PublicKey(assetData.compression.creator_hash.trim()).toBytes(),
    ],
    nonce: assetData.compression.leaf_id,
    index: assetData.compression.leaf_id,
  },
);

Conclusion #

We’ve covered the primary skills needed to interact with cNFTs, but haven’t been fully comprehensive. You can also use Bubblegum to do things like burn, verify, delegate, and more. We won’t go through these, but these instructions are similar to the mint and transfer process. If you need this additional functionality, take a look at the Bubblegum client source code and leverage the helper functions it provides.

Keep in mind that compression is fairly new. Available tooling will evolve rapidly but the principles you’ve learned in this lesson will likely remain the same. These principles can also be broadened to arbitrary state compression, so be sure to master them here so you’re ready for more fun stuff in future lessons!

Lab #

Let’s jump in and practice creating and working with cNFTs. Together, we’ll build as simple a script as possible that will let us mint a cNFT collection from a Merkle tree.

1. Get the starter code #

First things first, clone the starter code from the starter branch of our cNFT lab repository.

git clone https://github.com/Unboxed-Software/solana-cnft-demo.git

cd solana-cnft-demo

npm install

Take some time to familiarize yourself with the starter code provided. Most important are the helper functions provided in utils.ts and the URIs provided in uri.ts.

The uri.ts file provides 10k URIs that you can use for the offchain portion of your NFT metadata. You can, of course, create your own metadata. But this lesson isn’t explicitly about preparing metadata so we’ve provided some for you.

The utils.ts file has a few helper functions to keep you from writing more unnecessary boilerplate than you need to. They are as follows:

  • getOrCreateKeypair will create a new keypair for you and save it to a .env file, or if there’s already a private key in the .env file it will initialize a keypair from that.
  • airdropSolIfNeeded will airdrop some Devnet SOL to a specified address if that address’s balance is below 1 SOL.
  • createNftMetadata will create the NFT metadata for a given creator public key and index. The metadata it’s getting is just dummy metadata using the URI corresponding to the provided index from the uri.ts list of URIs.
  • getOrCreateCollectionNFT will fetch the collection NFT from the address specified in .env or if there is none it will create a new one and add the address to .env.

Finally, there’s some boilerplate in index.ts that calls creates a new Devnet connection, calls getOrCreateKeypair to initialize a “wallet,” and calls airdropSolIfNeeded to fund the wallet if its balance is low.

We will be writing all of our code in the index.ts.

2. Create the Merkle tree account #

We’ll start by creating the Merkle tree account. Let’s encapsulate this in a function that will eventually create and initialize the account. We’ll put it below our main function in index.ts. Let’s call it createAndInitializeTree. For this function to work, it will need the following parameters:

  • connection - a Connection to use for interacting with the network.
  • payer - a Keypair that will pay for transactions.
  • maxDepthSizePair - a ValidDepthSizePair. This type comes from @solana/spl-account-compression. It’s a simple object with properties maxDepth and maxBufferSize that enforces a valid combination of the two values.
  • canopyDepth - a number for the canopy depth In the body of the function, we’ll generate a new address for the tree, then create the instruction for allocating a new Merkle tree account by calling createAllocTreeIx from @solana/spl-account-compression.
async function createAndInitializeTree(
  connection: Connection,
  payer: Keypair,
  maxDepthSizePair: ValidDepthSizePair,
  canopyDepth: number,
) {
  const treeKeypair = Keypair.generate();

  const allocTreeIx = await createAllocTreeIx(
    connection,
    treeKeypair.publicKey,
    payer.publicKey,
    maxDepthSizePair,
    canopyDepth,
  );
}

3. Use Bubblegum to initialize the Merkle tree and create the tree config account #

With the instruction for creating the tree ready to go, we can create an instruction for invoking create_tree on the Bubblegum program. This will initialize the Merkle tree account and create a new tree config account on the Bubblegum program.

This instruction needs us to provide the following:

  • accounts - an object of required accounts; this includes:
    • treeAuthority - this should be a PDA derived with the Merkle tree address and the Bubblegum program
    • merkleTree - the address of the Merkle tree
    • payer - the transaction fee payer
    • treeCreator - the address of the tree creator; we’ll make this the same as payer
    • logWrapper - make this the SPL_NOOP_PROGRAM_ID
    • compressionProgram - make this the SPL_ACCOUNT_COMPRESSION_PROGRAM_ID
  • args - a list of instruction arguments; this includes:
    • maxBufferSize - the buffer size from our function’s maxDepthSizePair parameter
    • maxDepth - the max depth from our function’s maxDepthSizePair parameter
    • public - whether or no the tree should be public; we’ll set this to false

Finally, we can add both instructions to a transaction and submit the transaction. Keep in mind that the transaction needs to be signed by both the payer and the treeKeypair.

async function createAndInitializeTree(
  connection: Connection,
  payer: Keypair,
  maxDepthSizePair: ValidDepthSizePair,
  canopyDepth: number,
) {
  const treeKeypair = Keypair.generate();

  const allocTreeIx = await createAllocTreeIx(
    connection,
    treeKeypair.publicKey,
    payer.publicKey,
    maxDepthSizePair,
    canopyDepth,
  );

  const [treeAuthority, _bump] = PublicKey.findProgramAddressSync(
    [treeKeypair.publicKey.toBuffer()],
    BUBBLEGUM_PROGRAM_ID,
  );

  const createTreeIx = createCreateTreeInstruction(
    {
      treeAuthority,
      merkleTree: treeKeypair.publicKey,
      payer: payer.publicKey,
      treeCreator: payer.publicKey,
      logWrapper: SPL_NOOP_PROGRAM_ID,
      compressionProgram: SPL_ACCOUNT_COMPRESSION_PROGRAM_ID,
    },
    {
      maxBufferSize: maxDepthSizePair.maxBufferSize,
      maxDepth: maxDepthSizePair.maxDepth,
      public: false,
    },
  );

  const tx = new Transaction().add(allocTreeIx, createTreeIx);
  tx.feePayer = payer.publicKey;

  try {
    const txSignature = await sendAndConfirmTransaction(
      connection,
      tx,
      [treeKeypair, payer],
      {
        commitment: "confirmed",
        skipPreflight: true,
      },
    );

    console.log(`https://explorer.solana.com/tx/${txSignature}?cluster=devnet`);

    console.log("Tree Address:", treeKeypair.publicKey.toBase58());

    return treeKeypair.publicKey;
  } catch (err: any) {
    console.error("\nFailed to create Merkle tree:", err);
    throw err;
  }
}

If you want to test what you have so far, feel free to call createAndInitializeTree from main and provide small values for the max depth and max buffer size.

async function main() {
  const connection = new Connection(clusterApiUrl("devnet"), "confirmed");
  const wallet = await getOrCreateKeypair("Wallet_1");
  await airdropSolIfNeeded(wallet.publicKey);

  const maxDepthSizePair: ValidDepthSizePair = {
    maxDepth: 3,
    maxBufferSize: 8,
  };

  const canopyDepth = 0;

  const treeAddress = await createAndInitializeTree(
    connection,
    wallet,
    maxDepthSizePair,
    canopyDepth,
  );
}

Keep in mind that Devnet SOL is throttled so if you test too many times you might run out of Devnet SOL before we get to minting. To test, in your terminal run the following:

npm run start

4. Mint cNFTs to your tree #

Believe it or not, that’s all you needed to do to set up your tree to compressed NFTs! Now let’s turn our attention to minting.

First, let’s declare a function called mintCompressedNftToCollection. It will need the following parameters:

  • connection - a Connection to use for interacting with the network.
  • payer - a Keypair that will pay for transactions.
  • treeAddress - the Merkle tree’s address
  • collectionDetails - the details of the collection as type CollectionDetails from utils.ts
  • amount - the number of cNFTs to mint

The body of this function will do the following:

  1. Derive the tree authority just like before. Again, this is a PDA derived from the Merkle tree address and the Bubblegum program.
  2. Derive the bubblegumSigner. This is a PDA derived from the string "collection_cpi" and the Bubblegum program and is essential for minting to a collection.
  3. Create the cNFT metadata by calling createNftMetadata from our utils.ts file.
  4. Create the mint instruction by calling createMintToCollectionV1Instruction from the Bubblegum SDK.
  5. Build and send a transaction with the mint instruction
  6. Repeat steps 3-6 amount number of times

The createMintToCollectionV1Instruction takes two arguments: accounts and args. The latter is simply the NFT metadata. As with all complex instructions, the primary hurdle is knowing which accounts to provide. So let’s go through them real quick:

  • payer - the account that will pay for the transaction fees, rent, etc.
  • merkleTree - the Merkle tree account
  • treeAuthority - the tree authority; should be the same PDA you derived previously
  • treeDelegate - the tree delegate; this is usually the same as the tree creator
  • leafOwner - the desired owner of the compressed NFT being minted
  • leafDelegate - the desired delegate of the compressed NFT being minted; this is usually the same as the leaf owner
  • collectionAuthority - the authority of the collection NFT
  • collectionAuthorityRecordPda - optional collection authority record PDA; there typically is none, in which case you should put the Bubblegum program address
  • collectionMint - the mint account for the collection NFT
  • collectionMetadata - the metadata account for the collection NFT
  • editionAccount - the master edition account of the collection NFT
  • compressionProgram - the compression program to use; this should be the address of the SPL State Compression program unless you have some other custom implementation
  • logWrapper - the program to use to expose the data to indexers through logs; this should be the address of the SPL Noop program unless you have some other custom implementation
  • bubblegumSigner - a PDA used by the Bubblegrum program to handle collection verification
  • tokenMetadataProgram - the token metadata program that was used for the collection NFT; this is usually always the Metaplex Token Metadata program

When you put it all together, this is what it’ll look like:

async function mintCompressedNftToCollection(
  connection: Connection,
  payer: Keypair,
  treeAddress: PublicKey,
  collectionDetails: CollectionDetails,
  amount: number,
) {
  // Derive the tree authority PDA ('TreeConfig' account for the tree account)
  const [treeAuthority] = PublicKey.findProgramAddressSync(
    [treeAddress.toBuffer()],
    BUBBLEGUM_PROGRAM_ID,
  );

  // Derive the bubblegum signer, used by the Bubblegum program to handle "collection verification"
  // Only used for `createMintToCollectionV1` instruction
  const [bubblegumSigner] = PublicKey.findProgramAddressSync(
    [Buffer.from("collection_cpi", "utf8")],
    BUBBLEGUM_PROGRAM_ID,
  );

  for (let i = 0; i < amount; i++) {
    // Compressed NFT Metadata
    const compressedNFTMetadata = createNftMetadata(payer.publicKey, i);

    // Create the instruction to "mint" the compressed NFT to the tree
    const mintIx = createMintToCollectionV1Instruction(
      {
        payer: payer.publicKey, // The account that will pay for the transaction
        merkleTree: treeAddress, // The address of the tree account
        treeAuthority, // The authority of the tree account, should be a PDA derived from the tree account address
        treeDelegate: payer.publicKey, // The delegate of the tree account, should be the same as the tree creator by default
        leafOwner: payer.publicKey, // The owner of the compressed NFT being minted to the tree
        leafDelegate: payer.publicKey, // The delegate of the compressed NFT being minted to the tree
        collectionAuthority: payer.publicKey, // The authority of the "collection" NFT
        collectionAuthorityRecordPda: BUBBLEGUM_PROGRAM_ID, // Must be the Bubblegum program id
        collectionMint: collectionDetails.mint, // The mint of the "collection" NFT
        collectionMetadata: collectionDetails.metadata, // The metadata of the "collection" NFT
        editionAccount: collectionDetails.masterEditionAccount, // The master edition of the "collection" NFT
        compressionProgram: SPL_ACCOUNT_COMPRESSION_PROGRAM_ID,
        logWrapper: SPL_NOOP_PROGRAM_ID,
        bubblegumSigner,
        tokenMetadataProgram: TOKEN_METADATA_PROGRAM_ID,
      },
      {
        metadataArgs: Object.assign(compressedNFTMetadata, {
          collection: { key: collectionDetails.mint, verified: false },
        }),
      },
    );

    try {
      // Create new transaction and add the instruction
      const tx = new Transaction().add(mintIx);

      // Set the fee payer for the transaction
      tx.feePayer = payer.publicKey;

      // Send the transaction
      const txSignature = await sendAndConfirmTransaction(
        connection,
        tx,
        [payer],
        { commitment: "confirmed", skipPreflight: true },
      );

      console.log(
        `https://explorer.solana.com/tx/${txSignature}?cluster=devnet`,
      );
    } catch (err) {
      console.error("\nFailed to mint compressed NFT:", err);
      throw err;
    }
  }
}

This is a great point to test with a small tree. Simply update main to call getOrCreateCollectionNFT then mintCompressedNftToCollection:

async function main() {
  const connection = new Connection(clusterApiUrl("devnet"), "confirmed");
  const wallet = await getOrCreateKeypair("Wallet_1");
  await airdropSolIfNeeded(wallet.publicKey);

  const maxDepthSizePair: ValidDepthSizePair = {
    maxDepth: 3,
    maxBufferSize: 8,
  };

  const canopyDepth = 0;

  const treeAddress = await createAndInitializeTree(
    connection,
    wallet,
    maxDepthSizePair,
    canopyDepth,
  );

  const collectionNft = await getOrCreateCollectionNFT(connection, wallet);

  await mintCompressedNftToCollection(
    connection,
    wallet,
    treeAddress,
    collectionNft,
    2 ** maxDepthSizePair.maxDepth,
  );
}

Again, to run, in your terminal type: npm run start

5. Read existing cNFT data #

Now that we’ve written code to mint cNFTs, let’s see if we can actually fetch their data. This is tricky because the onchain data is just the Merkle tree account, the data from which can be used to verify existing information as accurate but is useless in conveying what the information is.

Let’s start by declaring a function logNftDetails that takes as parameters treeAddress and nftsMinted.

At this point we don’t actually have a direct identifier of any kind that points to our cNFT. To get that, we’ll need to know the leaf index that was used when we minted our cNFT. We can then use that to derive the asset ID used by the Read API and subsequently use the Read API to fetch our cNFT data.

In our case, we created a non-public tree and minted 8 cNFTs, so we know that the leaf indexes used were 0-7. With this, we can use the getLeafAssetId function from @metaplex-foundation/mpl-bubblegum to get the asset ID.

Finally, we can use an RPC that supports the Read API to fetch the asset. We’ll be using Helius, but feel free to choose your own RPC provider. To use Helius, you’ll need to get a free API Key from the Helius website. Then add your RPC_URL to your .env file. For example:

## Add this
RPC_URL=https://devnet.helius-rpc.com/?api-key=YOUR_API_KEY

Then simply issue a POST request to your provided RPC URL and put the getAsset information in the body:

async function logNftDetails(treeAddress: PublicKey, nftsMinted: number) {
  for (let i = 0; i < nftsMinted; i++) {
    const assetId = await getLeafAssetId(treeAddress, new BN(i));
    console.log("Asset ID:", assetId.toBase58());
    const response = await fetch(process.env.RPC_URL, {
      method: "POST",
      headers: { "Content-Type": "application/json" },
      body: JSON.stringify({
        jsonrpc: "2.0",
        id: "my-id",
        method: "getAsset",
        params: {
          id: assetId,
        },
      }),
    });
    const { result } = await response.json();
    console.log(JSON.stringify(result, null, 2));
  }
}

Helius essentially observes transaction logs as they happen and stores the NFT metadata that was hashed and stored in the Merkle tree. This enables them to surface that data when requested.

If we add a call to this function at the end of main and re-run your script, the data we get back in the console is very comprehensive. It includes all of the data you’d expect in both the onchain and offchain portion of a traditional NFT. You can find the cNFT’s attributes, files, ownership and creator information, and more.

{
  "interface": "V1_NFT",
  "id": "48Bw561h1fGFK4JGPXnmksHp2fpniEL7hefEc6uLZPWN",
  "content": {
    "$schema": "https://schema.metaplex.com/nft1.0.json",
    "json_uri": "https://raw.githubusercontent.com/Unboxed-Software/rgb-png-generator/master/assets/183_89_78/183_89_78.json",
    "files": [
      {
        "uri": "https://raw.githubusercontent.com/Unboxed-Software/rgb-png-generator/master/assets/183_89_78/183_89_78.png",
        "cdn_uri": "https://cdn.helius-rpc.com/cdn-cgi/image//https://raw.githubusercontent.com/Unboxed-Software/rgb-png-generator/master/assets/183_89_78/183_89_78.png",
        "mime": "image/png"
      }
    ],
    "metadata": {
      "attributes": [
        {
          "value": "183",
          "trait_type": "R"
        },
        {
          "value": "89",
          "trait_type": "G"
        },
        {
          "value": "78",
          "trait_type": "B"
        }
      ],
      "description": "Random RGB Color",
      "name": "CNFT",
      "symbol": "CNFT"
    },
    "links": {
      "image": "https://raw.githubusercontent.com/Unboxed-Software/rgb-png-generator/master/assets/183_89_78/183_89_78.png"
    }
  },
  "authorities": [
    {
      "address": "DeogHav5T2UV1zf5XuH4DTwwE5fZZt7Z4evytUUtDtHd",
      "scopes": ["full"]
    }
  ],
  "compression": {
    "eligible": false,
    "compressed": true,
    "data_hash": "3RsXHMBDpUPojPLZuMyKgZ1kbhW81YSY3PYmPZhbAx8K",
    "creator_hash": "Di6ufEixhht76sxutC9528H7PaWuPz9hqTaCiQxoFdr",
    "asset_hash": "2TwWjQPdGc5oVripPRCazGBpAyC5Ar1cia8YKUERDepE",
    "tree": "7Ge8nhDv2FcmnpyfvuWPnawxquS6gSidum38oq91Q7vE",
    "seq": 8,
    "leaf_id": 7
  },
  "grouping": [
    {
      "group_key": "collection",
      "group_value": "9p2RqBUAadMznAFiBEawMJnKR9EkFV98wKgwAz8nxLmj"
    }
  ],
  "royalty": {
    "royalty_model": "creators",
    "target": null,
    "percent": 0,
    "basis_points": 0,
    "primary_sale_happened": false,
    "locked": false
  },
  "creators": [
    {
      "address": "HASk3AoTPAvC1KnXSo6Qm73zpkEtEhbmjLpXLgvyKBkR",
      "share": 100,
      "verified": false
    }
  ],
  "ownership": {
    "frozen": false,
    "delegated": false,
    "delegate": null,
    "ownership_model": "single",
    "owner": "HASk3AoTPAvC1KnXSo6Qm73zpkEtEhbmjLpXLgvyKBkR"
  },
  "supply": {
    "print_max_supply": 0,
    "print_current_supply": 0,
    "edition_nonce": 0
  },
  "mutable": false,
  "burnt": false
}

Remember, the Read API also includes ways to get multiple assets, query by owner, creator, etc., and more. Be sure to look through the Helius docs to see what’s available.

6. Transfer a cNFT #

The last thing we’re going to add to our script is a cNFT transfer. Just as with a standard SPL token transfer, security is paramount. Unlike with a standard SPL token transfer, however, to build a secure transfer with state compression of any kind, the program performing the transfer needs the entire asset data.

The program, Bubblegum in this case, needs to be provided with the entire data that was hashed and stored on the corresponding leaf and needs to be given the “proof path” for the leaf in question. That makes cNFT transfers a bit trickier than SPL token transfers.

Remember, the general steps are:

  1. Fetch the cNFT's asset data from the indexer
  2. Fetch the cNFT's proof from the indexer
  3. Fetch the Merkle tree account from the Solana blockchain
  4. Prepare the asset proof as a list of AccountMeta objects
  5. Build and send the Bubblegum transfer instruction

Let’s start by declaring a transferNft function that takes the following:

  • connection - a Connection object
  • assetId - a PublicKey object
  • sender - a Keypair object so we can sign the transaction
  • receiver - a PublicKey object representing the new owner

Inside that function, let’s fetch the asset data again then also fetch the asset proof. For good measure, let’s wrap everything in a try catch.

async function transferNft(
  connection: Connection,
  assetId: PublicKey,
  sender: Keypair,
  receiver: PublicKey,
) {
  try {
    const assetDataResponse = await fetch(process.env.RPC_URL, {
      method: "POST",
      headers: { "Content-Type": "application/json" },
      body: JSON.stringify({
        jsonrpc: "2.0",
        id: "my-id",
        method: "getAsset",
        params: {
          id: assetId,
        },
      }),
    });
    const assetData = (await assetDataResponse.json()).result;

    const assetProofResponse = await fetch(process.env.RPC_URL, {
      method: "POST",
      headers: { "Content-Type": "application/json" },
      body: JSON.stringify({
        jsonrpc: "2.0",
        id: "my-id",
        method: "getAssetProof",
        params: {
          id: assetId,
        },
      }),
    });
    const assetProof = (await assetProofResponse.json()).result;
  } catch (err: any) {
    console.error("\nFailed to transfer nft:", err);
    throw err;
  }
}

Next, let’s fetch the Merkle tree account from the chain, get the canopy depth, and assemble the proof path. We do this by mapping the asset proof we got from Helius to a list of AccountMeta objects, then removing any proof nodes at the end that are already cached onchain in the canopy.

async function transferNft(
  connection: Connection,
  assetId: PublicKey,
  sender: Keypair,
  receiver: PublicKey
) {
  try {
    ...

    const treePublicKey = new PublicKey(assetData.compression.tree)

    const treeAccount = await ConcurrentMerkleTreeAccount.fromAccountAddress(
      connection,
      treePublicKey
    )

    const canopyDepth = treeAccount.getCanopyDepth() || 0

    const proofPath: AccountMeta[] = assetProof.proof
      .map((node: string) => ({
        pubkey: new PublicKey(node),
        isSigner: false,
        isWritable: false,
      }))
      .slice(0, assetProof.proof.length - canopyDepth)
  } catch (err: any) {
    console.error("\nFailed to transfer nft:", err)
    throw err
  }
}

Finally, we build the instruction using createTransferInstruction, add it to a transaction, then sign and send the transaction. This is what the entire transferNft function looks like when finished:

async function transferNft(
  connection: Connection,
  assetId: PublicKey,
  sender: Keypair,
  receiver: PublicKey,
) {
  try {
    const assetDataResponse = await fetch(process.env.RPC_URL, {
      method: "POST",
      headers: { "Content-Type": "application/json" },
      body: JSON.stringify({
        jsonrpc: "2.0",
        id: "my-id",
        method: "getAsset",
        params: {
          id: assetId,
        },
      }),
    });
    const assetData = (await assetDataResponse.json()).result;

    const assetProofResponse = await fetch(process.env.RPC_URL, {
      method: "POST",
      headers: { "Content-Type": "application/json" },
      body: JSON.stringify({
        jsonrpc: "2.0",
        id: "my-id",
        method: "getAssetProof",
        params: {
          id: assetId,
        },
      }),
    });
    const assetProof = (await assetProofResponse.json()).result;

    const treePublicKey = new PublicKey(assetData.compression.tree);

    const treeAccount = await ConcurrentMerkleTreeAccount.fromAccountAddress(
      connection,
      treePublicKey,
    );

    const canopyDepth = treeAccount.getCanopyDepth() || 0;

    const proofPath: AccountMeta[] = assetProof.proof
      .map((node: string) => ({
        pubkey: new PublicKey(node),
        isSigner: false,
        isWritable: false,
      }))
      .slice(0, assetProof.proof.length - canopyDepth);

    const treeAuthority = treeAccount.getAuthority();
    const leafOwner = new PublicKey(assetData.ownership.owner);
    const leafDelegate = assetData.ownership.delegate
      ? new PublicKey(assetData.ownership.delegate)
      : leafOwner;

    const transferIx = createTransferInstruction(
      {
        merkleTree: treePublicKey,
        treeAuthority,
        leafOwner,
        leafDelegate,
        newLeafOwner: receiver,
        logWrapper: SPL_NOOP_PROGRAM_ID,
        compressionProgram: SPL_ACCOUNT_COMPRESSION_PROGRAM_ID,
        anchorRemainingAccounts: proofPath,
      },
      {
        root: [...new PublicKey(assetProof.root.trim()).toBytes()],
        dataHash: [
          ...new PublicKey(assetData.compression.data_hash.trim()).toBytes(),
        ],
        creatorHash: [
          ...new PublicKey(assetData.compression.creator_hash.trim()).toBytes(),
        ],
        nonce: assetData.compression.leaf_id,
        index: assetData.compression.leaf_id,
      },
    );

    const tx = new Transaction().add(transferIx);
    tx.feePayer = sender.publicKey;
    const txSignature = await sendAndConfirmTransaction(
      connection,
      tx,
      [sender],
      {
        commitment: "confirmed",
        skipPreflight: true,
      },
    );
    console.log(`https://explorer.solana.com/tx/${txSignature}?cluster=devnet`);
  } catch (err: any) {
    console.error("\nFailed to transfer nft:", err);
    throw err;
  }
}

Lets transfer our first compressed NFT at index 0 to someone else. First we’ll need to spin up another wallet with some funds, then grab the assetID at index 0 using getLeafAssetId. Then we’ll do the transfer. Finally, we’ll print out the entire collection using our function logNftDetails. You’ll note that the NFT at index zero will now belong to our new wallet in the ownership field.

async function main() {
  const connection = new Connection(clusterApiUrl("devnet"), "confirmed");
  const wallet = await getOrCreateKeypair("Wallet_1");
  await airdropSolIfNeeded(wallet.publicKey);

  const maxDepthSizePair: ValidDepthSizePair = {
    maxDepth: 3,
    maxBufferSize: 8,
  };

  const canopyDepth = 0;

  const treeAddress = await createAndInitializeTree(
    connection,
    wallet,
    maxDepthSizePair,
    canopyDepth,
  );

  const collectionNft = await getOrCreateCollectionNFT(connection, wallet);

  await mintCompressedNftToCollection(
    connection,
    wallet,
    treeAddress,
    collectionNft,
    2 ** maxDepthSizePair.maxDepth,
  );

  const recieverWallet = await getOrCreateKeypair("Wallet_2");
  const assetId = await getLeafAssetId(treeAddress, new BN(0));
  await airdropSolIfNeeded(recieverWallet.publicKey);

  console.log(
    `Transfering ${assetId.toString()} from ${wallet.publicKey.toString()} to ${recieverWallet.publicKey.toString()}`,
  );

  await transferNft(connection, assetId, wallet, recieverWallet.publicKey);

  await logNftDetails(treeAddress, 8);
}

Go ahead and run your script. The whole thing should execute without failing, and all for close to 0.01 SOL!

Congratulations! Now you know how to mint, read, and transfer cNFTs. If you wanted, you could update the max depth, max buffer size, and canopy depth to larger values and as long as you have enough Devnet SOL, this script will let you mint up to 10k cNFTs for a small fraction of what it would cost to mint 10k traditional NFTs.

Info

If you plan to mint a large amount of NFTs you might want to try and batch these instructions for fewer total transactions.

If you need more time with this lab, feel free to go through it again and/or take a look at the solution code on the solution branch of the lab repo.

Challenge #

It’s your turn to take these concepts for a spin on your own! We’re not going to be overly prescriptive at this point, but here are some ideas:

  1. Create your own production cNFT collection
  2. Build a UI for this lesson’s lab that will let you mint a cNFT and display it
  3. See if you can replicate some of the lab script’s functionality in an onchain program, i.e. write a program that can mint cNFTs
Completed the lab?

Push your code to GitHub and tell us what you thought of this lesson!

Managed by

© 2024 Solana Foundation. All rights reserved.
Solana
Get Connected
© 2024 Solana Foundation. All rights reserved.
