MoneyMQ x402 Payment Protocol Demo

A complete demonstration of the x402 payment protocol integrated with MoneyMQ, enabling micropayment-protected APIs on Solana. This template shows how to build APIs that charge cryptocurrency payments per request, with payments verified on Solana and settled automatically.

Everything runs locally on your machine - no external services required, no mainnet, no real money. The demo includes a local Solana blockchain, payment facilitator, API server, and client, all with pre-seeded test accounts ready to use.

What You'll Build

By the end of this guide, you'll have:

A payment-protected API that charges $0.0001 per request using the x402 protocol
A MoneyMQ facilitator that verifies and settles payments on local Solana
A demo client showing the complete payment flow from request to access

When you run the demo, you'll see:

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
X402 + MONEYMQ PAYMENT FLOW DEMONSTRATION
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

[1/4] Initializing payment signer
  → Network: solana
  → Payer address: DVGD...YiNT
  ✓ Signer initialized

[2/4] Attempting to access protected endpoint without payment
  → GET http://localhost:4021/protected
  → Response: 402 Payment Required
  ✅ Status code: 402

[3/4] Accessing protected endpoint with x402 payment
  → Using x402 fetch wrapper
  → Payment will be processed via MoneyMQ facilitator
  → Transaction submitted to local Solana
  ✅ Status code: 200

[4/4] Processing response data
  ✓ Payment response decoded

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
SUCCESS: Payment completed and API accessed
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

Features

x402 Payment Protocol - HTTP 402 "Payment Required" standard for API monetization
MoneyMQ Integration - Built-in facilitator for payment verification and settlement
Local Solana Blockchain - Embedded validator for development and testing
Pre-seeded Test Accounts - Ready-to-use wallets with USDC balance
Zero Configuration - Everything works out of the box
TypeScript - Fully typed client and server code

What is x402?

x402 is an open payment protocol that uses HTTP status code 402 "Payment Required" to enable seamless cryptocurrency payments for web content and APIs.

Key Benefits:

Direct Payments - Accept cryptocurrency without third-party payment processors
No User Accounts - No registration or authentication required
Blockchain-Verified - Payments verified directly on Solana
AI Agent Compatible - Enable AI agents to autonomously pay for API services
Standard HTTP - Works with existing web infrastructure

How It Works:

Client requests protected content → Server responds with 402 Payment Required
Client creates payment transaction with x402 fetch wrapper
Client sends payment to facilitator for verification
Facilitator validates and settles transaction on Solana
Server verifies payment and returns protected content

What is MoneyMQ?

MoneyMQ is a standalone CLI that provides:

Built-in Facilitator - x402 payment verification and settlement (powered by Kora)
Local Blockchain - Embedded Solana validator for development (powered by Surfpool)
Pre-seeded Accounts - Test accounts with USDC ready to use
Fee Management - Automatic handling of transaction fees
Studio Web UI (Local) - View account balances and keys at http://localhost:8488/integrate

In this demo, MoneyMQ handles all blockchain complexity, letting you focus on building your API.

Prerequisites

Before you start, make sure you have:

Rust (latest stable) - Install Rust
Node.js 18+ - Download Node.js
pnpm - Install with npm install -g pnpm
Basic understanding of Solana transactions

Setup Steps

1. Install MoneyMQ

First, install the MoneyMQ CLI tool:

git clone https://github.com/txtx/moneymq.git
cd moneymq
cargo moneymq-install

This installs the moneymq command globally. You can verify with:

moneymq --version

2. Clone this template

git clone https://github.com/solana-foundation/templates.git
cd templates/community/moneymq-x402

This gets you the demo code with the API server and client.

3. Install dependencies

Install Node.js dependencies for both the API and client:

# Install dependencies for both API and client
pnpm run install:all

This installs all required packages including x402-express for the server and x402-fetch for the client.

4. Configure environment variables

Copy the example environment file:

cp .env.example .env

The .env file contains pre-configured addresses that work with MoneyMQ sandbox:

# MoneyMQ facilitator URL
FACILITATOR_URL=http://localhost:7781

# API configuration
PROTECTED_API_URL=http://localhost:4021/protected
API_PORT=4021

# The address that receives payments
PAYOUT_RECIPIENT_ADDRESS=62CwiUCt7o2ygfSrBmL941X2XvWqNdcStBk9rWDWMiep

# Customer wallet (pre-seeded with 2000 USDC)
PAYER_ADDRESS=DVGD278xQEJxKhYZBPkcPEbcncFV6HsdwUoe45LNYiNT
PAYER_PRIVATE_KEY=4SQ3kBvLqeAXoRMhXgRUG27ehizp6R5vQMhu4HAM3R8g...

# Enable debug logging (optional)
DEBUG=false

Note: These addresses are automatically created by MoneyMQ sandbox with pre-seeded USDC balances. You don't need to change them for local testing.

Running the Demo

You'll need three terminal windows to run all components.

Terminal 1: Start MoneyMQ Sandbox

From your MoneyMQ repository (not this directory):

moneymq sandbox

You should see:

# Payment API (protocol: x402, paying with 3iR5o1byE3RaMdZ5nWv5dEajSmTJsNUTFVUcnRumCgMU)
   GET http://localhost:7781/supported
  POST http://localhost:7781/verify
  POST http://localhost:7781/settle

MoneyMQ Studio:: http://localhost:8488 - Press Ctrl+C to stop

MoneyMQ Studio Dashboard:

MoneyMQ includes a web interface for monitoring your local blockchain. Open http://localhost:8488 to see the dashboard:

MoneyMQ Studio Dashboard

View Pre-Seeded Accounts:

Navigate to the Integrate page to see all test accounts with their USDC balances and private keys. This is helpful for understanding which accounts are being used:

MoneyMQ Studio Accounts

The sandbox provides:

x402 Facilitator at http://localhost:7781 - Verifies and settles payments
Local Solana RPC at http://localhost:8899 - Local blockchain for testing
Pre-seeded Accounts - Multiple test wallets with 2000 USDC each

Terminal 2: Start Protected API

pnpm run start:api

You should see:

Server listening at http://localhost:4021

This starts the payment-protected API server using x402-express middleware.

Terminal 3: Run Client Demo

pnpm run demo

You should see the complete payment flow demonstration with output showing:

Payment signer initialization
Failed request without payment (402 status)
Successful payment via MoneyMQ facilitator
Access granted with payment receipt

The client demonstrates how to use the x402-fetch wrapper to automatically handle payments when accessing protected endpoints.

View Transaction in MoneyMQ Studio:

After the demo runs successfully, you can view the payment transaction in MoneyMQ Studio. The transaction view shows the payment details, including the sender, recipient, and amount:

MoneyMQ Studio Transaction View

Understanding the Code

The Protected API Server

The API server (api/src/api.ts) uses the x402-express middleware to protect endpoints:

import { Network, paymentMiddleware, SolanaAddress } from 'x402-express'

const PAYOUT_RECIPIENT_ADDRESS = process.env.PAYOUT_RECIPIENT_ADDRESS as SolanaAddress
const FACILITATOR_URL = process.env.FACILITATOR_URL

app.use(
  paymentMiddleware(
    PAYOUT_RECIPIENT_ADDRESS, // Where payments are sent
    {
      'GET /protected': {
        price: '$0.0001', // Price per request
        network: 'solana',
      },
    },
    {
      url: FACILITATOR_URL, // MoneyMQ facilitator
    },
  ),
)

app.get('/protected', (req, res) => {
  res.json({
    message: 'Protected endpoint accessed successfully',
    timestamp: new Date().toISOString(),
  })
})

What happens:

Middleware intercepts requests to /protected
Returns 402 status if payment is missing or invalid
Validates payments via MoneyMQ facilitator
Allows access after successful payment verification

The Client Application

The client (client/src/index.ts) demonstrates the x402 payment flow:

import { createSigner, wrapFetchWithPayment } from 'x402-fetch'

// Create signer from private key
const payer = await createSigner('solana', PAYER_PRIVATE_KEY)

// Wrap fetch with x402 payment capabilities
const fetchWithPayment = wrapFetchWithPayment(fetch, payer, undefined, undefined, {
  svmConfig: { rpcUrl: 'http://localhost:8899' },
})

// First attempt: Regular fetch (fails with 402)
const expect402Response = await fetch(PROTECTED_API_URL)
console.log(`Status: ${expect402Response.status}`) // 402

// Second attempt: Fetch with payment (succeeds)
const response = await fetchWithPayment(PROTECTED_API_URL)
console.log(`Status: ${response.status}`) // 200

What the x402 fetch wrapper does:

Detects 402 responses from the server
Creates payment transaction based on server requirements
Signs transaction with user's private key
Submits to MoneyMQ for verification and settlement
Retries request with payment proof
Returns successful response with content

Customizing the Demo

Change API Pricing

Edit api/src/api.ts to adjust prices or add more endpoints:

app.use(
  paymentMiddleware(
    PAYOUT_RECIPIENT_ADDRESS,
    {
      'GET /protected': {
        price: '$0.0001',
        network: 'solana',
      },
      'GET /premium': {
        price: '$0.01',
        network: 'solana',
      },
      'POST /api/data': {
        price: '$0.05',
        network: 'solana',
      },
    },
    {
      url: FACILITATOR_URL,
    },
  ),
)

Then add corresponding route handlers:

app.get('/premium', (req, res) => {
  res.json({ message: 'Premium content accessed' })
})

Enable Debug Logging

Set DEBUG=true in your .env file to see detailed logs:

DEBUG=true

This shows:

Request/response details
Payment transaction data
Facilitator verification steps
Transaction signatures

Troubleshooting

Issue	Solution
Port already in use (7781, 8899, 4021)	Check what's using the ports with `lsof -i :PORT` and stop conflicting processes
MoneyMQ not found	Make sure you ran `cargo moneymq-install` and the binary is in your PATH
402 errors not resolving	Verify MoneyMQ sandbox is running and accessible at `http://localhost:7781`
USDC balance too low	Visit `http://localhost:8488/integrate` to view account balances. Sandbox accounts start with 2000 USDC
RPC connection errors	Ensure local Solana validator is healthy: `curl http://localhost:8899 -X POST -H "Content-Type: application/json" -d '{"jsonrpc":"2.0","id":1,"method":"getHealth"}'`
Payment verification fails	Check that `FACILITATOR_URL` in `.env` matches MoneyMQ sandbox URL (`http://localhost:7781`)
Module not found errors	Run `pnpm install` in both `api/` and `client/` directories

If you're still stuck, check the terminal where each service is running. Error messages usually indicate the specific issue.

Project Structure

moneymq-x402/
├── api/
│   ├── src/
│   │   └── api.ts              # Express server with x402 middleware
│   └── package.json            # API dependencies
├── client/
│   ├── src/
│   │   └── index.ts            # Demo client with x402-fetch
│   ├── package.json            # Client dependencies
│   └── tsconfig.json
├── .env.example                # Environment template
├── package.json                # Root package with convenience scripts
└── README.md

Key Files:

api/src/api.ts - Payment-protected API using x402-express middleware
client/src/index.ts - Demo client showing payment flow with x402-fetch
.env.example - Pre-configured environment variables for local testing

Use Cases

This architecture enables:

AI Agent Marketplaces - Let AI agents autonomously pay for API services
Pay-Per-Use APIs - Charge for individual API calls instead of subscriptions
Micropayment Content - Monetize content with tiny per-access fees
Usage-Based SaaS - Bill based on actual consumption
Decentralized Services - Enable services without centralized payment processors

Additional Resources

x402 Protocol

MoneyMQ

Kora (Powers MoneyMQ's Facilitator)

Kora GitHub
Kora x402 Demo - Original implementation this demo is based on
Kora Configuration Guide

Solana

Acknowledgments

This template demonstrates the x402 payment protocol integration with MoneyMQ. The facilitator implementation is powered by Kora, the Solana Foundation's gasless transaction signing infrastructure.

Credits: This example is heavily inspired by the original Kora x402 demo. We're grateful to the Kora team for pioneering this integration pattern.

License

MIT License - Feel free to use this template for your projects.
