Permanent Delegate

What Is a Permanent Delegate?

The Token Extension Program's PermanentDelegate mint extension assigns a delegate authority to the mint itself.

A permanent delegate is a mint level authority that can authorize transfers and burns for any token account for that mint. It acts as a global delegate for all token accounts for the mint, and token account owners cannot revoke the permanent delegate from their token accounts.

The mint authority can also rotate the permanent delegate later with SetAuthority using AuthorityType::PermanentDelegate.

How to Create and Use a Permanent Delegate

To create and use a permanent delegate:

Calculate the mint account size and rent needed for the mint and the PermanentDelegate extension.
Create the mint account with CreateAccount, initialize PermanentDelegate, and initialize the mint with InitializeMint.
Submit TransferChecked or BurnChecked signed by the permanent delegate. The token program processes those instructions the same way as if the token account owner signed them.

Calculate account size

Calculate the mint account size for the base mint plus the PermanentDelegate extension. This is the size used in CreateAccount.

Example

const client = await createClient()
  .use(generatedPayer())
  .use(
    solanaRpc({
      rpcUrl: "http://localhost:8899",
      rpcSubscriptionsUrl: "ws://localhost:8900"
    })
  )
  .use(rpcAirdrop())
  .use(airdropPayer(lamports(1_000_000_000n)));

const mint = await generateKeyPairSigner();
const owner = await generateKeyPairSigner();
const delegate = await generateKeyPairSigner();
const recipient = await generateKeyPairSigner();

const permanentDelegateExtension = extension("PermanentDelegate", {
  delegate: delegate.address
});

const mintSpace = BigInt(getMintSize([permanentDelegateExtension]));

Calculate rent

Calculate rent using the size needed for the mint plus the PermanentDelegate extension.

Example

const client = await createClient()
  .use(generatedPayer())
  .use(
    solanaRpc({
      rpcUrl: "http://localhost:8899",
      rpcSubscriptionsUrl: "ws://localhost:8900"
    })
  )
  .use(rpcAirdrop())
  .use(airdropPayer(lamports(1_000_000_000n)));

const mint = await generateKeyPairSigner();
const owner = await generateKeyPairSigner();
const delegate = await generateKeyPairSigner();
const recipient = await generateKeyPairSigner();

const permanentDelegateExtension = extension("PermanentDelegate", {
  delegate: delegate.address
});

const mintSpace = BigInt(getMintSize([permanentDelegateExtension]));

const mintRent = await client.rpc
  .getMinimumBalanceForRentExemption(mintSpace)
  .send();

Create the mint account

Create the mint account with the calculated space and lamports.

Example

const client = await createClient()
  .use(generatedPayer())
  .use(
    solanaRpc({
      rpcUrl: "http://localhost:8899",
      rpcSubscriptionsUrl: "ws://localhost:8900"
    })
  )
  .use(rpcAirdrop())
  .use(airdropPayer(lamports(1_000_000_000n)));

const mint = await generateKeyPairSigner();
const owner = await generateKeyPairSigner();
const delegate = await generateKeyPairSigner();
const recipient = await generateKeyPairSigner();

const permanentDelegateExtension = extension("PermanentDelegate", {
  delegate: delegate.address
});

const mintSpace = BigInt(getMintSize([permanentDelegateExtension]));

const mintRent = await client.rpc
  .getMinimumBalanceForRentExemption(mintSpace)
  .send();

await client.sendTransaction([
  getCreateAccountInstruction({
    payer: client.payer,
    newAccount: mint,
    lamports: mintRent,
    space: mintSpace,
    programAddress: TOKEN_2022_PROGRAM_ADDRESS
  })
]);

Initialize PermanentDelegate

Initialize the PermanentDelegate extension on the mint.

Example

const client = await createClient()
  .use(generatedPayer())
  .use(
    solanaRpc({
      rpcUrl: "http://localhost:8899",
      rpcSubscriptionsUrl: "ws://localhost:8900"
    })
  )
  .use(rpcAirdrop())
  .use(airdropPayer(lamports(1_000_000_000n)));

const mint = await generateKeyPairSigner();
const owner = await generateKeyPairSigner();
const delegate = await generateKeyPairSigner();
const recipient = await generateKeyPairSigner();

const permanentDelegateExtension = extension("PermanentDelegate", {
  delegate: delegate.address
});

const mintSpace = BigInt(getMintSize([permanentDelegateExtension]));

const mintRent = await client.rpc
  .getMinimumBalanceForRentExemption(mintSpace)
  .send();

await client.sendTransaction([
  getCreateAccountInstruction({
    payer: client.payer,
    newAccount: mint,
    lamports: mintRent,
    space: mintSpace,
    programAddress: TOKEN_2022_PROGRAM_ADDRESS
  }),
  getInitializePermanentDelegateInstruction({
    mint: mint.address,
    delegate: delegate.address
  })
]);

Initialize the mint

Initialize the mint with InitializeMint in the same transaction.

Example

const client = await createClient()
  .use(generatedPayer())
  .use(
    solanaRpc({
      rpcUrl: "http://localhost:8899",
      rpcSubscriptionsUrl: "ws://localhost:8900"
    })
  )
  .use(rpcAirdrop())
  .use(airdropPayer(lamports(1_000_000_000n)));

const mint = await generateKeyPairSigner();
const owner = await generateKeyPairSigner();
const delegate = await generateKeyPairSigner();
const recipient = await generateKeyPairSigner();

const permanentDelegateExtension = extension("PermanentDelegate", {
  delegate: delegate.address
});

const mintSpace = BigInt(getMintSize([permanentDelegateExtension]));

const mintRent = await client.rpc
  .getMinimumBalanceForRentExemption(mintSpace)
  .send();

await client.sendTransaction([
  getCreateAccountInstruction({
    payer: client.payer,
    newAccount: mint,
    lamports: mintRent,
    space: mintSpace,
    programAddress: TOKEN_2022_PROGRAM_ADDRESS
  }),
  getInitializePermanentDelegateInstruction({
    mint: mint.address,
    delegate: delegate.address
  }),
  getInitializeMintInstruction({
    mint: mint.address,
    decimals: 0,
    mintAuthority: client.payer.address,
    freezeAuthority: client.payer.address
  })
]);

Create token accounts and mint tokens

Create token accounts for the owner and recipient, then mint tokens to the owner token account.

Example

const client = await createClient()
  .use(generatedPayer())
  .use(
    solanaRpc({
      rpcUrl: "http://localhost:8899",
      rpcSubscriptionsUrl: "ws://localhost:8900"
    })
  )
  .use(rpcAirdrop())
  .use(airdropPayer(lamports(1_000_000_000n)));

const mint = await generateKeyPairSigner();
const owner = await generateKeyPairSigner();
const delegate = await generateKeyPairSigner();
const recipient = await generateKeyPairSigner();

const permanentDelegateExtension = extension("PermanentDelegate", {
  delegate: delegate.address
});

const mintSpace = BigInt(getMintSize([permanentDelegateExtension]));

const mintRent = await client.rpc
  .getMinimumBalanceForRentExemption(mintSpace)
  .send();

await client.sendTransaction([
  getCreateAccountInstruction({
    payer: client.payer,
    newAccount: mint,
    lamports: mintRent,
    space: mintSpace,
    programAddress: TOKEN_2022_PROGRAM_ADDRESS
  }),
  getInitializePermanentDelegateInstruction({
    mint: mint.address,
    delegate: delegate.address
  }),
  getInitializeMintInstruction({
    mint: mint.address,
    decimals: 0,
    mintAuthority: client.payer.address,
    freezeAuthority: client.payer.address
  })
]);

const [sourceToken] = await findAssociatedTokenPda({
  mint: mint.address,
  owner: owner.address,
  tokenProgram: TOKEN_2022_PROGRAM_ADDRESS
});
const [destinationToken] = await findAssociatedTokenPda({
  mint: mint.address,
  owner: recipient.address,
  tokenProgram: TOKEN_2022_PROGRAM_ADDRESS
});

await client.sendTransaction([
  await getCreateAssociatedTokenInstructionAsync({
    payer: client.payer,
    mint: mint.address,
    owner: owner.address
  }),
  await getCreateAssociatedTokenInstructionAsync({
    payer: client.payer,
    mint: mint.address,
    owner: recipient.address
  }),
  getMintToCheckedInstruction({
    mint: mint.address,
    token: sourceToken,
    mintAuthority: client.payer,
    amount: 1n,
    decimals: 0
  })
]);

Transfer with the permanent delegate

Transfer tokens with TransferChecked signed by the permanent delegate.

Example

const client = await createClient()
  .use(generatedPayer())
  .use(
    solanaRpc({
      rpcUrl: "http://localhost:8899",
      rpcSubscriptionsUrl: "ws://localhost:8900"
    })
  )
  .use(rpcAirdrop())
  .use(airdropPayer(lamports(1_000_000_000n)));

const mint = await generateKeyPairSigner();
const owner = await generateKeyPairSigner();
const delegate = await generateKeyPairSigner();
const recipient = await generateKeyPairSigner();

const permanentDelegateExtension = extension("PermanentDelegate", {
  delegate: delegate.address
});

const mintSpace = BigInt(getMintSize([permanentDelegateExtension]));

const mintRent = await client.rpc
  .getMinimumBalanceForRentExemption(mintSpace)
  .send();

await client.sendTransaction([
  getCreateAccountInstruction({
    payer: client.payer,
    newAccount: mint,
    lamports: mintRent,
    space: mintSpace,
    programAddress: TOKEN_2022_PROGRAM_ADDRESS
  }),
  getInitializePermanentDelegateInstruction({
    mint: mint.address,
    delegate: delegate.address
  }),
  getInitializeMintInstruction({
    mint: mint.address,
    decimals: 0,
    mintAuthority: client.payer.address,
    freezeAuthority: client.payer.address
  })
]);

const [sourceToken] = await findAssociatedTokenPda({
  mint: mint.address,
  owner: owner.address,
  tokenProgram: TOKEN_2022_PROGRAM_ADDRESS
});
const [destinationToken] = await findAssociatedTokenPda({
  mint: mint.address,
  owner: recipient.address,
  tokenProgram: TOKEN_2022_PROGRAM_ADDRESS
});

await client.sendTransaction([
  await getCreateAssociatedTokenInstructionAsync({
    payer: client.payer,
    mint: mint.address,
    owner: owner.address
  }),
  await getCreateAssociatedTokenInstructionAsync({
    payer: client.payer,
    mint: mint.address,
    owner: recipient.address
  }),
  getMintToCheckedInstruction({
    mint: mint.address,
    token: sourceToken,
    mintAuthority: client.payer,
    amount: 1n,
    decimals: 0
  })
]);

await client.sendTransaction([
  getTransferCheckedInstruction({
    source: sourceToken,
    mint: mint.address,
    destination: destinationToken,
    authority: delegate,
    amount: 1n,
    decimals: 0
  })
]);

Calculate account size

Calculate the mint account size for the base mint plus the PermanentDelegate extension. This is the size used in CreateAccount.

Calculate rent

Calculate rent using the size needed for the mint plus the PermanentDelegate extension.

Create the mint account

Create the mint account with the calculated space and lamports.

Initialize PermanentDelegate

Initialize the PermanentDelegate extension on the mint.

Initialize the mint

Initialize the mint with InitializeMint in the same transaction.

Create token accounts and mint tokens

Create token accounts for the owner and recipient, then mint tokens to the owner token account.

Transfer with the permanent delegate

Transfer tokens with TransferChecked signed by the permanent delegate.

Example

const client = await createClient()
  .use(generatedPayer())
  .use(
    solanaRpc({
      rpcUrl: "http://localhost:8899",
      rpcSubscriptionsUrl: "ws://localhost:8900"
    })
  )
  .use(rpcAirdrop())
  .use(airdropPayer(lamports(1_000_000_000n)));

const mint = await generateKeyPairSigner();
const owner = await generateKeyPairSigner();
const delegate = await generateKeyPairSigner();
const recipient = await generateKeyPairSigner();

const permanentDelegateExtension = extension("PermanentDelegate", {
  delegate: delegate.address
});

const mintSpace = BigInt(getMintSize([permanentDelegateExtension]));

Instruction Order

InitializePermanentDelegate must come before InitializeMint. CreateAccount, InitializePermanentDelegate, and InitializeMint must be included in the same transaction.

Source Reference

Item	Description	Source
`PermanentDelegate`	Mint extension that stores the delegate authorized across every token account for the mint.	Source
`InitializePermanentDelegate`	Instruction that initializes the permanent delegate before `InitializeMint`.	Source
`SetAuthority`	Base token instruction used with `AuthorityType::PermanentDelegate` to rotate the delegate.	Source
`AuthorityType::PermanentDelegate`	Authority discriminator used with `SetAuthority` to rotate the permanent delegate on a mint.	Source
`process_initialize_permanent_delegate`	Processor logic that writes the permanent delegate extension onto the mint.	Source
`process_set_authority`	Processor logic that validates and rotates the permanent delegate when `AuthorityType::PermanentDelegate` is used.	Source

Typescript

The Kit example below uses the generated instructions directly. Legacy examples using @solana/web3.js and @solana/spl-token are included for reference.

Kit

Instructions

import {
  lamports,
  createClient,
  generateKeyPairSigner,
  unwrapOption
} from "@solana/kit";
import { solanaRpc, rpcAirdrop } from "@solana/kit-plugin-rpc";
import { generatedPayer, airdropPayer } from "@solana/kit-plugin-signer";
import { getCreateAccountInstruction } from "@solana-program/system";
import {
  extension,
  fetchMint,
  fetchToken,
  findAssociatedTokenPda,
  getCreateAssociatedTokenInstructionAsync,
  getInitializeMintInstruction,
  getInitializePermanentDelegateInstruction,
  getMintSize,
  getMintToCheckedInstruction,
  getTransferCheckedInstruction,
  isExtension,
  TOKEN_2022_PROGRAM_ADDRESS
} from "@solana-program/token-2022";
const client = await createClient()
  .use(generatedPayer())
  .use(
    solanaRpc({
      rpcUrl: "http://localhost:8899",
      rpcSubscriptionsUrl: "ws://localhost:8900"
    })
  )
  .use(rpcAirdrop())
  .use(airdropPayer(lamports(1_000_000_000n)));

const mint = await generateKeyPairSigner();
const owner = await generateKeyPairSigner();
const delegate = await generateKeyPairSigner();
const recipient = await generateKeyPairSigner();

const permanentDelegateExtension = extension("PermanentDelegate", {
  delegate: delegate.address
});
const mintSpace = BigInt(getMintSize([permanentDelegateExtension]));
const mintRent = await client.rpc
  .getMinimumBalanceForRentExemption(mintSpace)
  .send();

await client.sendTransaction([
  getCreateAccountInstruction({
    payer: client.payer, // Account funding the new mint account.
    newAccount: mint, // New mint account to create.
    lamports: mintRent, // Lamports funding the mint account rent.
    space: mintSpace, // Account size in bytes for the mint plus PermanentDelegate.
    programAddress: TOKEN_2022_PROGRAM_ADDRESS // Program that owns the mint account.
  }),
  getInitializePermanentDelegateInstruction({
    mint: mint.address, // Mint account that stores the PermanentDelegate extension.
    delegate: delegate.address // Permanent delegate authorized for all token accounts for the mint.
  }),
  getInitializeMintInstruction({
    mint: mint.address, // Mint account to initialize.
    decimals: 0, // Number of decimals for the token.
    mintAuthority: client.payer.address, // Authority allowed to mint new tokens.
    freezeAuthority: client.payer.address // Authority allowed to freeze token accounts.
  })
]);

const [sourceToken] = await findAssociatedTokenPda({
  mint: mint.address,
  owner: owner.address,
  tokenProgram: TOKEN_2022_PROGRAM_ADDRESS
});
const [destinationToken] = await findAssociatedTokenPda({
  mint: mint.address,
  owner: recipient.address,
  tokenProgram: TOKEN_2022_PROGRAM_ADDRESS
});

await client.sendTransaction([
  await getCreateAssociatedTokenInstructionAsync({
    payer: client.payer, // Account funding the associated token account creation.
    mint: mint.address, // Mint for the associated token account.
    owner: owner.address // Owner of the source token account.
  }),
  await getCreateAssociatedTokenInstructionAsync({
    payer: client.payer, // Account funding the associated token account creation.
    mint: mint.address, // Mint for the associated token account.
    owner: recipient.address // Owner of the destination token account.
  }),
  getMintToCheckedInstruction({
    mint: mint.address, // Mint account that issues the tokens.
    token: sourceToken, // Token account receiving the newly minted tokens.
    mintAuthority: client.payer, // Signer authorized to mint new tokens.
    amount: 1n, // Token amount in base units.
    decimals: 0 // Decimals defined on the mint.
  })
]);

await client.sendTransaction([
  getTransferCheckedInstruction({
    source: sourceToken, // Token account sending the transfer.
    mint: mint.address, // Mint with the permanent delegate configuration.
    destination: destinationToken, // Token account receiving the transfer.
    authority: delegate, // Permanent delegate signing the transfer.
    amount: 1n, // Token amount in base units.
    decimals: 0 // Decimals defined on the mint.
  })
]);

const destinationAccount = await fetchToken(client.rpc, destinationToken);
const mintAccount = await fetchMint(client.rpc, mint.address);
const permanentDelegate = (
  unwrapOption(mintAccount.data.extensions) ?? []
).find((item) => isExtension("PermanentDelegate", item));

console.log("Mint Address:", mint.address);
console.log("Destination Amount:", destinationAccount.data.amount);
console.log("Permanent Delegate Extension:", permanentDelegate);

Console

Click to execute the code.

Instructions

import {
  lamports,
  createClient,
  generateKeyPairSigner,
  unwrapOption
} from "@solana/kit";
import { solanaRpc, rpcAirdrop } from "@solana/kit-plugin-rpc";
import { generatedPayer, airdropPayer } from "@solana/kit-plugin-signer";
import { getCreateAccountInstruction } from "@solana-program/system";
import {
  extension,
  fetchMint,
  fetchToken,
  findAssociatedTokenPda,
  getCreateAssociatedTokenInstructionAsync,
  getInitializeMintInstruction,
  getInitializePermanentDelegateInstruction,
  getMintSize,
  getMintToCheckedInstruction,
  getTransferCheckedInstruction,
  isExtension,
  TOKEN_2022_PROGRAM_ADDRESS
} from "@solana-program/token-2022";
const client = await createClient()
  .use(generatedPayer())
  .use(
    solanaRpc({
      rpcUrl: "http://localhost:8899",
      rpcSubscriptionsUrl: "ws://localhost:8900"
    })
  )
  .use(rpcAirdrop())
  .use(airdropPayer(lamports(1_000_000_000n)));

const mint = await generateKeyPairSigner();
const owner = await generateKeyPairSigner();
const delegate = await generateKeyPairSigner();
const recipient = await generateKeyPairSigner();

const permanentDelegateExtension = extension("PermanentDelegate", {
  delegate: delegate.address
});
const mintSpace = BigInt(getMintSize([permanentDelegateExtension]));
const mintRent = await client.rpc
  .getMinimumBalanceForRentExemption(mintSpace)
  .send();

await client.sendTransaction([
  getCreateAccountInstruction({
    payer: client.payer, // Account funding the new mint account.
    newAccount: mint, // New mint account to create.
    lamports: mintRent, // Lamports funding the mint account rent.
    space: mintSpace, // Account size in bytes for the mint plus PermanentDelegate.
    programAddress: TOKEN_2022_PROGRAM_ADDRESS // Program that owns the mint account.
  }),
  getInitializePermanentDelegateInstruction({
    mint: mint.address, // Mint account that stores the PermanentDelegate extension.
    delegate: delegate.address // Permanent delegate authorized for all token accounts for the mint.
  }),
  getInitializeMintInstruction({
    mint: mint.address, // Mint account to initialize.
    decimals: 0, // Number of decimals for the token.
    mintAuthority: client.payer.address, // Authority allowed to mint new tokens.
    freezeAuthority: client.payer.address // Authority allowed to freeze token accounts.
  })
]);

const [sourceToken] = await findAssociatedTokenPda({
  mint: mint.address,
  owner: owner.address,
  tokenProgram: TOKEN_2022_PROGRAM_ADDRESS
});
const [destinationToken] = await findAssociatedTokenPda({
  mint: mint.address,
  owner: recipient.address,
  tokenProgram: TOKEN_2022_PROGRAM_ADDRESS
});

await client.sendTransaction([
  await getCreateAssociatedTokenInstructionAsync({
    payer: client.payer, // Account funding the associated token account creation.
    mint: mint.address, // Mint for the associated token account.
    owner: owner.address // Owner of the source token account.
  }),
  await getCreateAssociatedTokenInstructionAsync({
    payer: client.payer, // Account funding the associated token account creation.
    mint: mint.address, // Mint for the associated token account.
    owner: recipient.address // Owner of the destination token account.
  }),
  getMintToCheckedInstruction({
    mint: mint.address, // Mint account that issues the tokens.
    token: sourceToken, // Token account receiving the newly minted tokens.
    mintAuthority: client.payer, // Signer authorized to mint new tokens.
    amount: 1n, // Token amount in base units.
    decimals: 0 // Decimals defined on the mint.
  })
]);

await client.sendTransaction([
  getTransferCheckedInstruction({
    source: sourceToken, // Token account sending the transfer.
    mint: mint.address, // Mint with the permanent delegate configuration.
    destination: destinationToken, // Token account receiving the transfer.
    authority: delegate, // Permanent delegate signing the transfer.
    amount: 1n, // Token amount in base units.
    decimals: 0 // Decimals defined on the mint.
  })
]);

const destinationAccount = await fetchToken(client.rpc, destinationToken);
const mintAccount = await fetchMint(client.rpc, mint.address);
const permanentDelegate = (
  unwrapOption(mintAccount.data.extensions) ?? []
).find((item) => isExtension("PermanentDelegate", item));

console.log("Mint Address:", mint.address);
console.log("Destination Amount:", destinationAccount.data.amount);
console.log("Permanent Delegate Extension:", permanentDelegate);

Console

Click to execute the code.

Web3.js

Instructions

import {
  Connection,
  Keypair,
  sendAndConfirmTransaction,
  SystemProgram,
  Transaction,
  LAMPORTS_PER_SOL
} from "@solana/web3.js";
import {
  ASSOCIATED_TOKEN_PROGRAM_ID,
  createAssociatedTokenAccountInstruction,
  createInitializeMintInstruction,
  createInitializePermanentDelegateInstruction,
  createMintToCheckedInstruction,
  createTransferCheckedInstruction,
  ExtensionType,
  getAccount,
  getAssociatedTokenAddressSync,
  getMint,
  getMintLen,
  getPermanentDelegate,
  TOKEN_2022_PROGRAM_ID
} from "@solana/spl-token";

const connection = new Connection("http://localhost:8899", "confirmed");
const latestBlockhash = await connection.getLatestBlockhash();

const feePayer = Keypair.generate();
const owner = Keypair.generate();
const delegate = Keypair.generate();
const recipient = Keypair.generate();

const airdropSignature = await connection.requestAirdrop(
  feePayer.publicKey,
  5 * LAMPORTS_PER_SOL
);
await connection.confirmTransaction({
  blockhash: latestBlockhash.blockhash,
  lastValidBlockHeight: latestBlockhash.lastValidBlockHeight,
  signature: airdropSignature
});

const extensions = [ExtensionType.PermanentDelegate];

const mint = Keypair.generate();
const mintLength = getMintLen(extensions);
const mintRent = await connection.getMinimumBalanceForRentExemption(mintLength);

const sourceToken = getAssociatedTokenAddressSync(
  mint.publicKey,
  owner.publicKey,
  false,
  TOKEN_2022_PROGRAM_ID,
  ASSOCIATED_TOKEN_PROGRAM_ID
);
const destinationToken = getAssociatedTokenAddressSync(
  mint.publicKey,
  recipient.publicKey,
  false,
  TOKEN_2022_PROGRAM_ID,
  ASSOCIATED_TOKEN_PROGRAM_ID
);

const createMintAccountInstruction = SystemProgram.createAccount({
  fromPubkey: feePayer.publicKey, // Account funding the new mint account.
  newAccountPubkey: mint.publicKey, // New mint account to create.
  space: mintLength, // Account size in bytes for the mint plus PermanentDelegate.
  lamports: mintRent, // Lamports funding the mint account rent.
  programId: TOKEN_2022_PROGRAM_ID // Program that owns the mint account.
});

const initializePermanentDelegateInstruction =
  createInitializePermanentDelegateInstruction(
    mint.publicKey, // Mint account that stores the PermanentDelegate extension.
    delegate.publicKey, // Permanent delegate authorized for all token accounts for the mint.
    TOKEN_2022_PROGRAM_ID // Token program that owns the mint.
  );

const initializeMintInstruction = createInitializeMintInstruction(
  mint.publicKey, // Mint account to initialize.
  0, // Number of decimals for the token.
  feePayer.publicKey, // Authority allowed to mint new tokens.
  feePayer.publicKey, // Authority allowed to freeze token accounts.
  TOKEN_2022_PROGRAM_ID // Program that owns the mint account.
);

await sendAndConfirmTransaction(
  connection,
  new Transaction().add(
    createMintAccountInstruction,
    initializePermanentDelegateInstruction,
    initializeMintInstruction
  ),
  [feePayer, mint],
  {
    commitment: "confirmed"
  }
);

await sendAndConfirmTransaction(
  connection,
  new Transaction().add(
    createAssociatedTokenAccountInstruction(
      feePayer.publicKey, // Account funding the associated token account creation.
      sourceToken, // Associated token account address to create.
      owner.publicKey, // Owner of the source token account.
      mint.publicKey, // Mint for the associated token account.
      TOKEN_2022_PROGRAM_ID, // Token program that owns the token account.
      ASSOCIATED_TOKEN_PROGRAM_ID // Associated Token Program that creates the account.
    ),
    createAssociatedTokenAccountInstruction(
      feePayer.publicKey, // Account funding the associated token account creation.
      destinationToken, // Associated token account address to create.
      recipient.publicKey, // Owner of the destination token account.
      mint.publicKey, // Mint for the associated token account.
      TOKEN_2022_PROGRAM_ID, // Token program that owns the token account.
      ASSOCIATED_TOKEN_PROGRAM_ID // Associated Token Program that creates the account.
    ),
    createMintToCheckedInstruction(
      mint.publicKey, // Mint account that issues the tokens.
      sourceToken, // Token account receiving the newly minted tokens.
      feePayer.publicKey, // Signer authorized to mint new tokens.
      1, // Token amount in base units.
      0, // Decimals defined on the mint.
      [], // Additional multisig signers.
      TOKEN_2022_PROGRAM_ID // Token program that owns the mint and token account.
    )
  ),
  [feePayer],
  {
    commitment: "confirmed"
  }
);

await sendAndConfirmTransaction(
  connection,
  new Transaction().add(
    createTransferCheckedInstruction(
      sourceToken, // Token account sending the transfer.
      mint.publicKey, // Mint with the permanent delegate configuration.
      destinationToken, // Token account receiving the transfer.
      delegate.publicKey, // Permanent delegate signing the transfer.
      1, // Token amount in base units.
      0, // Decimals defined on the mint.
      [], // Additional multisig signers.
      TOKEN_2022_PROGRAM_ID // Token program that processes the transfer.
    )
  ),
  [feePayer, delegate],
  {
    commitment: "confirmed"
  }
);

const destinationAccount = await getAccount(
  connection,
  destinationToken,
  "confirmed",
  TOKEN_2022_PROGRAM_ID
);
const mintAccount = await getMint(
  connection,
  mint.publicKey,
  "confirmed",
  TOKEN_2022_PROGRAM_ID
);
const permanentDelegate = getPermanentDelegate(mintAccount);

console.log("Mint Address:", mint.publicKey.toBase58());
console.log("Destination Amount:", destinationAccount.amount.toString());
console.log("Permanent Delegate Extension:", permanentDelegate);

Console

Click to execute the code.

Instructions

import {
  Connection,
  Keypair,
  sendAndConfirmTransaction,
  SystemProgram,
  Transaction,
  LAMPORTS_PER_SOL
} from "@solana/web3.js";
import {
  ASSOCIATED_TOKEN_PROGRAM_ID,
  createAssociatedTokenAccountInstruction,
  createInitializeMintInstruction,
  createInitializePermanentDelegateInstruction,
  createMintToCheckedInstruction,
  createTransferCheckedInstruction,
  ExtensionType,
  getAccount,
  getAssociatedTokenAddressSync,
  getMint,
  getMintLen,
  getPermanentDelegate,
  TOKEN_2022_PROGRAM_ID
} from "@solana/spl-token";

const connection = new Connection("http://localhost:8899", "confirmed");
const latestBlockhash = await connection.getLatestBlockhash();

const feePayer = Keypair.generate();
const owner = Keypair.generate();
const delegate = Keypair.generate();
const recipient = Keypair.generate();

const airdropSignature = await connection.requestAirdrop(
  feePayer.publicKey,
  5 * LAMPORTS_PER_SOL
);
await connection.confirmTransaction({
  blockhash: latestBlockhash.blockhash,
  lastValidBlockHeight: latestBlockhash.lastValidBlockHeight,
  signature: airdropSignature
});

const extensions = [ExtensionType.PermanentDelegate];

const mint = Keypair.generate();
const mintLength = getMintLen(extensions);
const mintRent = await connection.getMinimumBalanceForRentExemption(mintLength);

const sourceToken = getAssociatedTokenAddressSync(
  mint.publicKey,
  owner.publicKey,
  false,
  TOKEN_2022_PROGRAM_ID,
  ASSOCIATED_TOKEN_PROGRAM_ID
);
const destinationToken = getAssociatedTokenAddressSync(
  mint.publicKey,
  recipient.publicKey,
  false,
  TOKEN_2022_PROGRAM_ID,
  ASSOCIATED_TOKEN_PROGRAM_ID
);

const createMintAccountInstruction = SystemProgram.createAccount({
  fromPubkey: feePayer.publicKey, // Account funding the new mint account.
  newAccountPubkey: mint.publicKey, // New mint account to create.
  space: mintLength, // Account size in bytes for the mint plus PermanentDelegate.
  lamports: mintRent, // Lamports funding the mint account rent.
  programId: TOKEN_2022_PROGRAM_ID // Program that owns the mint account.
});

const initializePermanentDelegateInstruction =
  createInitializePermanentDelegateInstruction(
    mint.publicKey, // Mint account that stores the PermanentDelegate extension.
    delegate.publicKey, // Permanent delegate authorized for all token accounts for the mint.
    TOKEN_2022_PROGRAM_ID // Token program that owns the mint.
  );

const initializeMintInstruction = createInitializeMintInstruction(
  mint.publicKey, // Mint account to initialize.
  0, // Number of decimals for the token.
  feePayer.publicKey, // Authority allowed to mint new tokens.
  feePayer.publicKey, // Authority allowed to freeze token accounts.
  TOKEN_2022_PROGRAM_ID // Program that owns the mint account.
);

await sendAndConfirmTransaction(
  connection,
  new Transaction().add(
    createMintAccountInstruction,
    initializePermanentDelegateInstruction,
    initializeMintInstruction
  ),
  [feePayer, mint],
  {
    commitment: "confirmed"
  }
);

await sendAndConfirmTransaction(
  connection,
  new Transaction().add(
    createAssociatedTokenAccountInstruction(
      feePayer.publicKey, // Account funding the associated token account creation.
      sourceToken, // Associated token account address to create.
      owner.publicKey, // Owner of the source token account.
      mint.publicKey, // Mint for the associated token account.
      TOKEN_2022_PROGRAM_ID, // Token program that owns the token account.
      ASSOCIATED_TOKEN_PROGRAM_ID // Associated Token Program that creates the account.
    ),
    createAssociatedTokenAccountInstruction(
      feePayer.publicKey, // Account funding the associated token account creation.
      destinationToken, // Associated token account address to create.
      recipient.publicKey, // Owner of the destination token account.
      mint.publicKey, // Mint for the associated token account.
      TOKEN_2022_PROGRAM_ID, // Token program that owns the token account.
      ASSOCIATED_TOKEN_PROGRAM_ID // Associated Token Program that creates the account.
    ),
    createMintToCheckedInstruction(
      mint.publicKey, // Mint account that issues the tokens.
      sourceToken, // Token account receiving the newly minted tokens.
      feePayer.publicKey, // Signer authorized to mint new tokens.
      1, // Token amount in base units.
      0, // Decimals defined on the mint.
      [], // Additional multisig signers.
      TOKEN_2022_PROGRAM_ID // Token program that owns the mint and token account.
    )
  ),
  [feePayer],
  {
    commitment: "confirmed"
  }
);

await sendAndConfirmTransaction(
  connection,
  new Transaction().add(
    createTransferCheckedInstruction(
      sourceToken, // Token account sending the transfer.
      mint.publicKey, // Mint with the permanent delegate configuration.
      destinationToken, // Token account receiving the transfer.
      delegate.publicKey, // Permanent delegate signing the transfer.
      1, // Token amount in base units.
      0, // Decimals defined on the mint.
      [], // Additional multisig signers.
      TOKEN_2022_PROGRAM_ID // Token program that processes the transfer.
    )
  ),
  [feePayer, delegate],
  {
    commitment: "confirmed"
  }
);

const destinationAccount = await getAccount(
  connection,
  destinationToken,
  "confirmed",
  TOKEN_2022_PROGRAM_ID
);
const mintAccount = await getMint(
  connection,
  mint.publicKey,
  "confirmed",
  TOKEN_2022_PROGRAM_ID
);
const permanentDelegate = getPermanentDelegate(mintAccount);

console.log("Mint Address:", mint.publicKey.toBase58());
console.log("Destination Amount:", destinationAccount.amount.toString());
console.log("Permanent Delegate Extension:", permanentDelegate);

Console

Click to execute the code.

Rust

use anyhow::Result;
use solana_client::nonblocking::rpc_client::RpcClient;
use solana_commitment_config::CommitmentConfig;
use solana_sdk::{
    signature::{Keypair, Signer},
    transaction::Transaction,
};
use solana_system_interface::instruction::create_account;
use spl_associated_token_account_interface::{
    address::get_associated_token_address_with_program_id,
    instruction::create_associated_token_account,
};
use spl_token_2022_interface::{
    extension::{
        permanent_delegate::PermanentDelegate, BaseStateWithExtensions, ExtensionType,
        StateWithExtensions,
    },
    instruction::{
        initialize_mint, initialize_permanent_delegate, mint_to_checked, transfer_checked,
    },
    state::{Account, Mint},
    ID as TOKEN_2022_PROGRAM_ID,
};

#[tokio::main]
async fn main() -> Result<()> {
    let client = RpcClient::new_with_commitment(
        String::from("http://localhost:8899"),
        CommitmentConfig::confirmed(),
    );
    let fee_payer = Keypair::new();
    let owner = Keypair::new();
    let delegate = Keypair::new();
    let recipient = Keypair::new();

    let airdrop_signature = client
        .request_airdrop(&fee_payer.pubkey(), 5_000_000_000)
        .await?;

    loop {
        let confirmed = client.confirm_transaction(&airdrop_signature).await?;
        if confirmed {
            break;
        }
    }

    let mint = Keypair::new();

    let mint_space =
        ExtensionType::try_calculate_account_len::<Mint>(&[ExtensionType::PermanentDelegate])?;

    let mint_rent = client
        .get_minimum_balance_for_rent_exemption(mint_space)
        .await?;

    let create_mint_account_instruction = create_account(
        &fee_payer.pubkey(),    // Account funding the new mint account.
        &mint.pubkey(),         // New mint account to create.
        mint_rent,              // Lamports funding the mint account rent.
        mint_space as u64,      // Account size in bytes for the mint plus PermanentDelegate.
        &TOKEN_2022_PROGRAM_ID, // Program that owns the mint account.
    );

    let initialize_permanent_delegate_ix = initialize_permanent_delegate(
        &TOKEN_2022_PROGRAM_ID, // Token program that owns the mint.
        &mint.pubkey(), // Mint account that stores the PermanentDelegate extension.
        &delegate.pubkey(), // Permanent delegate authorized for all token accounts for the mint.
    )?;

    let initialize_mint_instruction = initialize_mint(
        &TOKEN_2022_PROGRAM_ID,    // Program that owns the mint account.
        &mint.pubkey(),            // Mint account to initialize.
        &fee_payer.pubkey(),       // Authority allowed to mint new tokens.
        Some(&fee_payer.pubkey()), // Authority allowed to freeze token accounts.
        0,                         // Number of decimals for the token.
    )?;

    let create_mint_transaction = Transaction::new_signed_with_payer(
        &[
            create_mint_account_instruction,
            initialize_permanent_delegate_ix,
            initialize_mint_instruction,
        ],
        Some(&fee_payer.pubkey()),
        &[&fee_payer, &mint],
        client.get_latest_blockhash().await?,
    );

    client
        .send_and_confirm_transaction(&create_mint_transaction)
        .await?;

    let source_token = get_associated_token_address_with_program_id(
        &owner.pubkey(),
        &mint.pubkey(),
        &TOKEN_2022_PROGRAM_ID,
    );
    let destination_token = get_associated_token_address_with_program_id(
        &recipient.pubkey(),
        &mint.pubkey(),
        &TOKEN_2022_PROGRAM_ID,
    );

    let create_token_accounts_transaction = Transaction::new_signed_with_payer(
        &[
            create_associated_token_account(
                &fee_payer.pubkey(), // Account funding the associated token account creation.
                &owner.pubkey(), // Owner of the source token account.
                &mint.pubkey(), // Mint for the associated token account.
                &TOKEN_2022_PROGRAM_ID, // Token program that owns the token account.
            ),
            create_associated_token_account(
                &fee_payer.pubkey(), // Account funding the associated token account creation.
                &recipient.pubkey(), // Owner of the destination token account.
                &mint.pubkey(), // Mint for the associated token account.
                &TOKEN_2022_PROGRAM_ID, // Token program that owns the token account.
            ),
            mint_to_checked(
                &TOKEN_2022_PROGRAM_ID, // Token program that owns the mint and token account.
                &mint.pubkey(), // Mint account that issues the tokens.
                &source_token, // Token account receiving the newly minted tokens.
                &fee_payer.pubkey(), // Signer authorized to mint new tokens.
                &[&fee_payer.pubkey()], // Additional multisig signers.
                1, // Token amount in base units.
                0, // Decimals defined on the mint.
            )?,
        ],
        Some(&fee_payer.pubkey()),
        &[&fee_payer],
        client.get_latest_blockhash().await?,
    );

    client
        .send_and_confirm_transaction(&create_token_accounts_transaction)
        .await?;

    let transfer_transaction = Transaction::new_signed_with_payer(
        &[
            transfer_checked(
                &TOKEN_2022_PROGRAM_ID, // Token program that processes the transfer.
                &source_token, // Token account sending the transfer.
                &mint.pubkey(), // Mint with the permanent delegate configuration.
                &destination_token, // Token account receiving the transfer.
                &delegate.pubkey(), // Permanent delegate signing the transfer.
                &[&delegate.pubkey()], // Additional multisig signers.
                1, // Token amount in base units.
                0, // Decimals defined on the mint.
            )?,
        ],
        Some(&fee_payer.pubkey()),
        &[&fee_payer, &delegate],
        client.get_latest_blockhash().await?,
    );

    client
        .send_and_confirm_transaction(&transfer_transaction)
        .await?;

    let destination_account = client.get_account(&destination_token).await?;
    let destination_state =
        StateWithExtensions::<Account>::unpack(&destination_account.data)?;
    let mint_account = client.get_account(&mint.pubkey()).await?;
    let mint_state = StateWithExtensions::<Mint>::unpack(&mint_account.data)?;
    let permanent_delegate = mint_state.get_extension::<PermanentDelegate>()?;

    println!("Mint Address: {}", mint.pubkey());
    println!(
        "Destination Amount: {}",
        u64::from(destination_state.base.amount)
    );
    println!("Permanent Delegate Extension: {:?}", permanent_delegate);

    Ok(())
}

Console

Click to execute the code.

Rust

use anyhow::Result;
use solana_client::nonblocking::rpc_client::RpcClient;
use solana_commitment_config::CommitmentConfig;
use solana_sdk::{
    signature::{Keypair, Signer},
    transaction::Transaction,
};
use solana_system_interface::instruction::create_account;
use spl_associated_token_account_interface::{
    address::get_associated_token_address_with_program_id,
    instruction::create_associated_token_account,
};
use spl_token_2022_interface::{
    extension::{
        permanent_delegate::PermanentDelegate, BaseStateWithExtensions, ExtensionType,
        StateWithExtensions,
    },
    instruction::{
        initialize_mint, initialize_permanent_delegate, mint_to_checked, transfer_checked,
    },
    state::{Account, Mint},
    ID as TOKEN_2022_PROGRAM_ID,
};

#[tokio::main]
async fn main() -> Result<()> {
    let client = RpcClient::new_with_commitment(
        String::from("http://localhost:8899"),
        CommitmentConfig::confirmed(),
    );
    let fee_payer = Keypair::new();
    let owner = Keypair::new();
    let delegate = Keypair::new();
    let recipient = Keypair::new();

    let airdrop_signature = client
        .request_airdrop(&fee_payer.pubkey(), 5_000_000_000)
        .await?;

    loop {
        let confirmed = client.confirm_transaction(&airdrop_signature).await?;
        if confirmed {
            break;
        }
    }

    let mint = Keypair::new();

    let mint_space =
        ExtensionType::try_calculate_account_len::<Mint>(&[ExtensionType::PermanentDelegate])?;

    let mint_rent = client
        .get_minimum_balance_for_rent_exemption(mint_space)
        .await?;

    let create_mint_account_instruction = create_account(
        &fee_payer.pubkey(),    // Account funding the new mint account.
        &mint.pubkey(),         // New mint account to create.
        mint_rent,              // Lamports funding the mint account rent.
        mint_space as u64,      // Account size in bytes for the mint plus PermanentDelegate.
        &TOKEN_2022_PROGRAM_ID, // Program that owns the mint account.
    );

    let initialize_permanent_delegate_ix = initialize_permanent_delegate(
        &TOKEN_2022_PROGRAM_ID, // Token program that owns the mint.
        &mint.pubkey(), // Mint account that stores the PermanentDelegate extension.
        &delegate.pubkey(), // Permanent delegate authorized for all token accounts for the mint.
    )?;

    let initialize_mint_instruction = initialize_mint(
        &TOKEN_2022_PROGRAM_ID,    // Program that owns the mint account.
        &mint.pubkey(),            // Mint account to initialize.
        &fee_payer.pubkey(),       // Authority allowed to mint new tokens.
        Some(&fee_payer.pubkey()), // Authority allowed to freeze token accounts.
        0,                         // Number of decimals for the token.
    )?;

    let create_mint_transaction = Transaction::new_signed_with_payer(
        &[
            create_mint_account_instruction,
            initialize_permanent_delegate_ix,
            initialize_mint_instruction,
        ],
        Some(&fee_payer.pubkey()),
        &[&fee_payer, &mint],
        client.get_latest_blockhash().await?,
    );

    client
        .send_and_confirm_transaction(&create_mint_transaction)
        .await?;

    let source_token = get_associated_token_address_with_program_id(
        &owner.pubkey(),
        &mint.pubkey(),
        &TOKEN_2022_PROGRAM_ID,
    );
    let destination_token = get_associated_token_address_with_program_id(
        &recipient.pubkey(),
        &mint.pubkey(),
        &TOKEN_2022_PROGRAM_ID,
    );

    let create_token_accounts_transaction = Transaction::new_signed_with_payer(
        &[
            create_associated_token_account(
                &fee_payer.pubkey(), // Account funding the associated token account creation.
                &owner.pubkey(), // Owner of the source token account.
                &mint.pubkey(), // Mint for the associated token account.
                &TOKEN_2022_PROGRAM_ID, // Token program that owns the token account.
            ),
            create_associated_token_account(
                &fee_payer.pubkey(), // Account funding the associated token account creation.
                &recipient.pubkey(), // Owner of the destination token account.
                &mint.pubkey(), // Mint for the associated token account.
                &TOKEN_2022_PROGRAM_ID, // Token program that owns the token account.
            ),
            mint_to_checked(
                &TOKEN_2022_PROGRAM_ID, // Token program that owns the mint and token account.
                &mint.pubkey(), // Mint account that issues the tokens.
                &source_token, // Token account receiving the newly minted tokens.
                &fee_payer.pubkey(), // Signer authorized to mint new tokens.
                &[&fee_payer.pubkey()], // Additional multisig signers.
                1, // Token amount in base units.
                0, // Decimals defined on the mint.
            )?,
        ],
        Some(&fee_payer.pubkey()),
        &[&fee_payer],
        client.get_latest_blockhash().await?,
    );

    client
        .send_and_confirm_transaction(&create_token_accounts_transaction)
        .await?;

    let transfer_transaction = Transaction::new_signed_with_payer(
        &[
            transfer_checked(
                &TOKEN_2022_PROGRAM_ID, // Token program that processes the transfer.
                &source_token, // Token account sending the transfer.
                &mint.pubkey(), // Mint with the permanent delegate configuration.
                &destination_token, // Token account receiving the transfer.
                &delegate.pubkey(), // Permanent delegate signing the transfer.
                &[&delegate.pubkey()], // Additional multisig signers.
                1, // Token amount in base units.
                0, // Decimals defined on the mint.
            )?,
        ],
        Some(&fee_payer.pubkey()),
        &[&fee_payer, &delegate],
        client.get_latest_blockhash().await?,
    );

    client
        .send_and_confirm_transaction(&transfer_transaction)
        .await?;

    let destination_account = client.get_account(&destination_token).await?;
    let destination_state =
        StateWithExtensions::<Account>::unpack(&destination_account.data)?;
    let mint_account = client.get_account(&mint.pubkey()).await?;
    let mint_state = StateWithExtensions::<Mint>::unpack(&mint_account.data)?;
    let permanent_delegate = mint_state.get_extension::<PermanentDelegate>()?;

    println!("Mint Address: {}", mint.pubkey());
    println!(
        "Destination Amount: {}",
        u64::from(destination_state.base.amount)
    );
    println!("Permanent Delegate Extension: {:?}", permanent_delegate);

    Ok(())
}

Console

Click to execute the code.

Calculate account size

Calculate rent

Create the mint account

Initialize PermanentDelegate

Initialize the mint

Create token accounts and mint tokens

Transfer with the permanent delegate

Calculate account size

Calculate rent

Create the mint account

Initialize PermanentDelegate

Initialize the mint

Create token accounts and mint tokens

Transfer with the permanent delegate

Table of Contents
